Bently Nevada 9200-02-01-10-00 Two-Wire Seismoprobe Velocity Transducer

Apenas 8 item(ns) restante(s) em estoque

Fabricante: Bently Nevada
Nº do Produto: 9200-02-01-10-00
País de origem:Estados Unidos
Tipo de Produto: Seismoprobe Velocity Transducers
Código de barras: 8537101190
Pagamento: T/T, Western Union
Peso: 300g
Dimensões: 11.5cm x 4cm x 4cm
Porto de embarque: Xiamen
Garantia: 12 meses

Description

The Bently Nevada 9200-02-01-10-00 is a two-wire velocity transducer engineered for continuous machinery vibration monitoring or periodic diagnostic measurements when paired with test instruments. This moving-coil device measures absolute casing vibration by generating a voltage proportional to the transducer's velocity. When selected with the integral cable configuration, the 9200-02-01-10-00 Seismoprobe provides superior resistance to corrosive environments, eliminating the need for external protective housings. It connects directly to monitoring systems to ensure dependable machinery protection and predictive maintenance data collection.

Features

Moving-coil design providing a self-generated voltage output proportional to velocity without external power.
Two-wire electrical configuration simplifying field wiring over long distances.
High resistance to corrosive atmospheres and environmental contaminants when equipped with the integral cable option.
Support for multi-angle mounting configurations optimized for specific directional vibration measurement.
Rugged mechanical housing designed to withstand harsh industrial environments.

Applications

Casing vibration monitoring on industrial pumps, fans, and blowers.
Predictive maintenance data collection on steam and gas turbines.
Continuous protection systems for gearboxes and large electric motors.
Diagnostic testing and structural vibration analysis in petrochemical and power generation plants.

Ordering Information

Option Code	Description
Model: 9200	Two-Wire Seismoprobe Velocity Transducer
02	Transducer Mounting Angle / Minimum Operating Frequency: 45 +/-2.5 degrees, 4.5 Hz (270 cpm)
01	Connector Option: Top mount
10	Mounting Base Option: Circular; M10X1 stud
00	Agency Approval Option: No approvals required

Technical Specifications

Parameter	Specification
Manufacturer	Bently Nevada
Country of Origin	United States
Sensitivity	20 mV/mm/s (500 mV/in/s), +/-5% at +22 degC (+72 degF) with 25 mm/s (1 in/s) machine casing vibration at 100 Hz (6000 cpm) with a 10 kilo ohm load
Frequency Response	From 4.5 Hz (270 cpm) to 1 kHz (60,000 cpm); +0, -3dB typical
Dynamic Operating Range	2.54 mm (0.100 in) peak-to-peak maximum displacement
Shock Resistance	Withstands 50 g peak maximum acceleration along nonsensitive axis
Transverse Sensitivity	+/-10% maximum
Maximum Leadwire Length	305 meters (1,000 feet) maximum between transducer and 3300 or 3500 Monitor
Operating & Storage Temperature	-29 degC to +121 degC (-20 degF to +250 degF)
Relative Humidity	Up to 95% noncondensing; 100% non-submerged when ordered with integral cable
Case & Adapter Material	Anodized aluminum A204
Gasket Material	Neoprene
Connector Material (Top/Side)	Cadmium-plated aluminum, neoprene, and silver-plated copper
Mounting Torque (M10x1 base)	5.6 Nm (50 inlb)
Height	102 mm (4 in) typical (depends on connector option)
Diameter	41 mm (1.6 in) typical
Weight	300 grams (10.5 ounces) typical

Connections/Interfaces

Connector Pin	Function
Pin A	Positive output signal (goes positive with respect to Pin B when case velocity moves toward connector)
Pin B	Negative output signal / Return

Installation Guidelines

Mounting Alignment: Ensure the transducer is installed at its specified calibration angle (45 degrees for option 02) to maintain proper frequency and sensitivity accuracy.
Torque Application: Tighten the M10x1 circular mounting base to exactly 5.6 Nm (50 inlb). Over-torquing can damage the internal components or casing threads.
Cable Routing: Avoid routing transducer cables parallel to high-voltage AC power lines to minimize electro-magnetic interference (EMI) injection into the signal path.
Moisture Protection: For installations exposed to heavy washdowns or high humidity, utilize the integral cable option or properly seal the mating connector backshell to prevent liquid ingress.

Compliance and Certifications

Category	Standard / Certification
EMC	EN61326-1, Electrical Equipment for Measurement, Control, and Laboratory use
European Directives	EMC Directive 2004/108/EC

Key Features:
