Siemens 6ES7647-6AC35-0FK0 SIMATIC BOX PC 627 Industrial PC

Остался только 3 товар(ы) на складе

Производитель: Siemens
Номер продукта: 6ES7647-6AC35-0FK0
Страна происхождения:Германия
Тип продукта: Industrial PC
Штрихкод: 85371091
Оплата: Т/Т, Western Union
Вес: 7150г
Размеры: 45.0 x 47.5 x 27.0 cm
Порт отгрузки: Сямынь
Гарантия: 12 месяцев

Description

The Siemens 6ES7647-6AC35-0FK0 is a SIMATIC BOX PC 627 designed for industrial applications. This unit is configured with a Pentium M 730 1.6 GHz processor, 256 MB of DDR2 RAM, and an 80 GB SATA hard disk drive. It features integrated AGP graphics, dual 10/100 Mbit/s Ethernet ports, and an onboard RAID controller for data integrity. The system is equipped with a 110/230V AC industrial power supply and includes a PCI interface card that provides additional COM2 and LPT1 ports. This model is supplied without a pre-installed operating system, providing flexibility for custom software deployment.

Features

Integrated AGP graphics with 8-128 MB shared memory
Dual 10/100 Mbit/s Ethernet RJ45 ports for network connectivity
Four high-current USB 2.0 ports
Onboard RAID controller for enhanced storage reliability
Internal slot for a CompactFlash drive
Integrated watchdog timer and temperature/fan monitoring
Two available PCI slots for hardware expansion
Includes a PCI interface card for COM2 and LPT1 ports

Applications

Human-Machine Interface (HMI) server
Data acquisition and logging systems
Industrial control and visualization nodes
Gateway for factory floor networks
Legacy system support and maintenance

Technical Specifications

Specification	Value
Manufacturer	Siemens
Product Line	SIMATIC BOX PC 627
Processor	Pentium M 730, 1.6 GHz, 533 MHz FSB, 2 MB SLC
Memory (RAM)	256 MB DDR2 533 SODIMM
Storage	80 GB SATA HDD
Graphics	Onboard AGP, 8-128 MB Shared Memory
Ethernet Interface	2 x 10/100 Mbit/s Ethernet (RJ45)
USB Interface	4 x USB V2.0 (High Current)
Serial Interface	1 x COM1 (onboard), 1 x COM2 (via PCI card)
Parallel Interface	1 x LPT1 (via PCI card)
Expansion Slots	2 x PCI (free)
Removable Media	1 x Slot for CompactFlash Drive
Power Supply	AC 110/230V Industrial Power Unit with NAMUR
Power Cable	Europe
Operating System	Not included
Product Status	Obsolete
Shipping Weight	7.15 kg
Package Dimensions (Calculated)	45.0 x 47.5 x 27.0 cm
Country of Origin	Germany (Estimate)
Commodity Code	85371091
ECCN	N

Installation Guidelines

CRITICAL WARNING: Electrical hazard. Installation must be performed by qualified personnel only. De-energize and lock out/tag out all power sources before accessing the control panel or attempting to install, wire, or service this device. Failure to comply can result in severe injury or death.

1
Mounting: Securely mount the Box PC inside a suitable industrial enclosure that provides protection against environmental factors. Ensure adequate clearance around the unit for ventilation and cable access.
2
Grounding: Connect the chassis ground terminal to the control panel's main protective earth (PE) bus bar using a low-impedance conductor. A proper ground connection is essential for safety and noise immunity.
3
Power Connection: Connect the AC 110/230V power supply to a stable, filtered power source. Use the provided European power cable or a suitable equivalent for your region. Ensure the power source voltage matches the supply rating.
4
I/O Wiring: Connect all required peripherals, including Ethernet, USB, and serial devices. Route signal cables separately from high-voltage power lines to minimize electromagnetic interference.
5
System Startup: After verifying all connections, restore power to the panel. Proceed with operating system and application software installation as required for the specific industrial task.

Key Features:

#Industrial PC #SIMATIC BOX PC 627

What processor is installed in the 6ES7647-6AC35-0FK0?

This SIMATIC BOX PC is equipped with an Intel Pentium M 730 processor running at 1.6 GHz with a 533 MHz Front Side Bus and 2 MB of L2 cache.

Does this industrial PC come with an operating system?

No, this unit is supplied without a pre-installed operating system, allowing for custom software installation based on application requirements.

What are the power supply requirements for this device?

The PC includes an industrial power supply unit compatible with AC 110V and 230V sources. It is supplied with a European standard power cable.

How many expansion slots are available?

This model provides two free PCI slots for installing additional interface cards or other expansion hardware.

What type of network ports are on this PC?

It features two standard 10/100 Mbit/s Ethernet ports with RJ45 connectors for connection to industrial networks.
