Danfoss 060G6763 MBS 3000 Pressure Transmitter

Description

The Danfoss 060G6763 is a high-performance MBS 3000 pressure transmitter designed for use in harsh industrial environments. This compact pressure transmitter is engineered to provide reliable and accurate pressure measurement for a wide range of applications, including hydraulic systems, pump control, and process monitoring. The device features a rugged design, ensuring long-term stability and resistance to shock and vibration.

Operating with a standard industrial current output signal (4–20 mA), the 060G6763 integrates seamlessly into PLC and DCS control systems. It is built to withstand demanding ambient conditions, with an operating temperature range of -40 Celsius to 85 Celsius and an IP65-rated enclosure, providing robust protection against dust and water jets.

Features

• Robust design for industrial pressure measurement
• Measuring range: -1 to 15 bar (-14.5 to 217.5 psi)
• Reliable 4-20 mA current output signal
• Wide supply voltage range: 9.00 V DC to 32.00 V DC
• IP65 ingress protection rating
• Compact form factor with EN 175301-803-A angular electrical connection
• High resistance to shock and vibration

Applications

• Hydraulic and pneumatic systems
• Compressor and pump monitoring
• Process plant automation
• HVAC and cooling systems
• General industrial machinery

Technical Specifications

Connections/Interfaces

Installation Guidelines

• Mounting: Install the transmitter in a location that minimizes liquid hammer and pressure surges.
• Orientation: For liquid applications, mount the sensor with the pressure connection facing downward to prevent air entrapment.
• Wiring: Use shielded cable for the 4-20 mA loop to mitigate electromagnetic interference (EMI). Ensure the EN 175301-803-A connector is fully tightened to maintain the IP65 seal.
• Power Supply: Ensure the supply voltage remains within the 9.00–32.00 V DC range to avoid signal inaccuracies or damage to the internal electronics.
• Environment: Avoid mounting the device in locations exceeding the maximum ambient temperature of 85 Celsius.
