Mitsubishi Electric HF-SN102BJ-S100 HF-SN Series AC Servo Motor

Description

Delivering precise motion control in demanding automation setups, the Mitsubishi Electric HF-SN102BJ-S100 operates as a medium-inertia rotary actuator designed for high-performance positioning systems. This motor belongs to the robust HF-SN Series, engineered to handle structural mechanical configurations with optimal speed-to-torque characteristics. Outfitted with an integrated electromagnetic brake and a robust oil seal, this motor provides reliable holding torque and shaft protection in harsh operating conditions. Its high-grade environmental sealing makes it suitable for wet, dusty, or high-vibration manufacturing environments.

Features

• High Torque Density: Engineered with a rated output of 1.0 kW to deliver consistent torque across its speed range.
• Integrated Electromagnetic Brake: Built-in safety braking mechanism provides secure position retention and emergency deceleration.
• Protective Oil Seal: Pre-installed shaft oil seal prevents the ingress of lubricants, cutting fluids, and coolants.
• IP67 Environmental Rating: Sealed enclosure protects the internal windings and stator against dust and water immersion.
• High Dynamic Response: Medium-inertia rotor design allows for excellent tracking control and stable operation under fluctuating loads.

Applications

• Machine Tool Axes: Precise feed-rate control for multi-axis milling, turning, and grinding machinery.
• Material Handling Systems: Dynamic positioning in automated storage, retrieval systems (ASRS), and transfer lines.
• Packaging Equipment: High-speed indexing, filling, cartoning, and sealing applications.
• Robotic Gantry Systems: Multi-axis overhead loaders requiring dependable holding braking.

Technical Specifications

Installation & Setup Guidelines
