Schneider Electric STBXTS2100 Modicon STB 6-Pin Removable Connector

Description

The STBXTS2100 is a removable screw terminal connector designed for use with Modicon STB distributed I/O modules. This accessory facilitates the reliable connection of field wiring to digital I/O modules within the STB automation platform. Its removable design allows for rapid installation, easy replacement, and efficient maintenance of field devices without the need to disconnect individual wires from the terminal block itself.

This kit includes 20 pieces, providing a convenient and cost-effective solution for equipping multiple I/O modules or for maintaining a ready inventory for system expansions and repairs. As an essential component for the Modicon STB ecosystem, it ensures secure electrical contact and robust mechanical stability in industrial environments.

Features

• Series: Modicon STB
• Configuration: 6-pin terminal block
• Design: Removable screw-type connector for efficient wiring and maintenance.
• Compatibility: Compatible with a wide range of Modicon STB digital I/O modules.
• Packaging: Sold in a kit of 20 units.

Technical Specifications

Installation Guidelines

• Preparation: Strip field wires to the appropriate length specified in the installation guide to ensure full insertion into the terminal.
• Insertion: Secure the wires into the connector terminals using a flat-head screwdriver. Ensure all screws are tightened to the recommended torque to prevent loose connections.
• Mounting: Carefully align the connector with the mating header on the Modicon STB module. Press firmly until the connector is fully seated and the locking tabs (if applicable) engage.
• Maintenance: For troubleshooting or module replacement, simply pull the connector block off the module. This allows for unit swapping without disturbing the field wiring termination.
