Siemens 6ES7647-6AE35-0JK3 SIMATIC Box PC 627 PC Box

Only 6 item(s) left in stock

Manufacturer: Siemens
Product No.: 6ES7647-6AE35-0JK3
Country of origin:เยอรมนี
Product Type: PC Box
Barcode: 85371091
Payment: T/T, Western Union
Weight: 7050g
Dimensions: 45.00 x 47.50 x 27.00 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Siemens 6ES7647-6AE35-0JK3 is a SIMATIC Box PC 627, designed for industrial applications requiring robust computing performance and connectivity. This unit features onboard AGP graphics with 8-128 MB shared memory, dual 10/100 Mbit/s Ethernet RJ45 ports, and four high-current USB V2.0 interfaces. It includes a serial (COM1) port and an onboard RAID controller. For storage, it provides a slot for a Compact Flash drive, a RAID1 configuration with two 60 GB SATA (2.5") drives, and a DVD+/-RW drive. The system is equipped with a Pentium M 760 2.0 GHz CPU, 1 GByte DDR2 533 SODIMM RAM, and operates on a DC 24V industrial power supply. Integrated monitoring functions include watchdog, temperature, and fan monitoring. The PC comes pre-installed with Windows XP Professional Multi-Language SP2 and includes SIMATIC PC DiagMonitor V3.1 and Image Creator Software V2.0.

Features

Onboard AGP graphics with 8-128 MB shared memory
2 x 10/100 Mbit/s Ethernet RJ45 ports
4 x USB V2.0 (High Current) ports
1 x Serial (COM1) port
Onboard RAID controller
1 x Slot for Compact Flash drive
Watchdog, temperature, and fan monitoring
2 x Free PCI slots
Pentium M 760 2.0 GHz CPU, 533 MHz FSB, 2 MB SLC
1 GByte DDR2 533 SODIMM RAM
DC 24V Industrial Power Supply
RAID1 configuration with 2 x 60 GB SATA (2.5") drives
DVD+/-RW drive
Pre-installed Windows XP Professional Multi-Language SP2 (EN, GE, FR, IT, SP)
Includes SIMATIC PC DiagMonitor V3.1 & Image Creator Software V2.0

Applications

The SIMATIC Box PC 627 is suitable for a wide range of industrial automation tasks, including:

Machine control and visualization
Data acquisition and processing
Human-Machine Interface (HMI) systems
SCADA (Supervisory Control and Data Acquisition) applications
Industrial communication gateways
Process control and monitoring

Technical Specifications

Manufacturer	Siemens
Range	Simatic Box PC
Subrange	PC627
Product Type	PC Box
CPU	Pentium M 760 2.0 GHz, 533 MHz FSB, 2 MB SLC
RAM	1 GByte DDR2 533 SODIMM
Graphics	AGP Graphics Onboard, 8-128 MB Shared Memory
Ethernet Ports	2 x 10/100 Mbit/s RJ45
USB Ports	4 x USB V2.0 (High Current)
Serial Port	1 x Serial (COM1)
Storage Controller	Onboard RAID Controller
Internal Storage	RAID1 / 2 x 60 GB SATA (2.5")
Optical Drive	DVD+/-RW
Expansion Slots	2 x PCI (free)
Memory Card Slot	1 x Compact Flash Drive
Monitoring	Watchdog, Temperature, Fan Monitoring
Operating System	Windows XP Professional Multi-Language SP2 (EN, GE, FR, IT, SP)
Included Software	SIMATIC PC DiagMonitor V3.1 & Image Creator Software V2.0
Power Supply	DC 24V Industrial Power Supply
Package Dimensions (Calculated)	45.00 x 47.50 x 27.00 cm
Shipping Weight	7.05 kg
Commodity Code	85371091
Export Control Regulations (ECCN)	N

Connections / Interfaces

Interface Type	Quantity	Description
Ethernet	2	RJ45, 10/100 Mbit/s
USB	4	USB V2.0 (High Current)
Serial	1	COM1
Compact Flash	1	Slot for Compact Flash Drive

Installation Guidelines

De-energize System: Ensure all power to the installation area is disconnected and locked out before beginning any work.
Mounting: Securely mount the Box PC in a suitable industrial enclosure or rack, ensuring adequate ventilation and clearance for cable routing and maintenance.
Power Connection: Connect the DC 24V industrial power supply to the designated power input terminals. Verify correct polarity before applying power.
Grounding: Establish a robust protective earth (PE) connection to the chassis of the Box PC to ensure electrical safety and minimize electromagnetic interference.
Ethernet Connections: Connect industrial Ethernet cables to the RJ45 ports for network communication. Use shielded cables in electrically noisy environments.
USB and Serial Connections: Connect USB devices and serial communication cables (e.g., for COM1) as required by the application.
Cable Routing: Route all cables to prevent strain, sharp bends, and interference with other components. Separate power and signal cables where possible.
Environmental Considerations: Ensure the operating environment meets the specified temperature and humidity ranges for industrial PC equipment.
Power On: After all connections are verified, re-energize the system and observe for proper startup and operation.

Key Features:

What is the primary power requirement for the SIMATIC Box PC 627?

The Siemens 6ES7647-6AE35-0JK3 requires a DC 24V industrial power supply for operation.

What operating system is pre-installed on this Box PC?

The unit comes with Windows XP Professional Multi-Language SP2 pre-installed, supporting English, German, French, Italian, and Spanish.

Does the PC include any diagnostic or imaging software?

Yes, it includes SIMATIC PC DiagMonitor V3.1 and Image Creator Software V2.0.

What type of internal storage is provided?

It features an onboard RAID controller with a RAID1 configuration using two 60 GB SATA (2.5") drives, along with a DVD+/-RW drive.

Are there any expansion slots available?

The SIMATIC Box PC 627 provides two free PCI slots for additional expansion cards.
