Lenze EMF2175IB 8200-series Fieldbus Module

Stokta sadece 6 adet kaldı

Üretici: Lenze
Ürün No.: EMF2175IB
Menşei ülke:Almanya
Ürün Türü: Fieldbus Modules
Barkod: 85044095
Ödeme: T/T, Western Union
Ağırlık: 100g
Boyutlar: 7.60 cm x 7.60 cm x 5.10 cm
Gönderim limanı: Xiamen
Garanti: 12 ay

Lenze EMF2175IB 8200-series Fieldbus Module

### Description Designed for seamless integration into industrial drive systems, the **EMF2175IB** serves as a high-performance communication interface within the Lenze **8200-series** frequency inverter ecosystem. This fieldbus module enables dual-protocol connectivity, supporting both **DeviceNet** and **CANopen** industrial networks. By facilitating direct digital control, parameterization, and diagnostics, the module eliminates the need for extensive analog wiring, providing robust real-time data exchange between the host controller and the drive. Its compact design allows for direct mounting onto the inverter, ensuring a secure and space-saving installation inside control cabinets. ### Features

Dual-protocol compatibility supporting both DeviceNet and CANopen communication standards.
Direct plug-in design engineered specifically for Lenze 8200-series frequency inverters.
Optically isolated communication interfaces to prevent ground loops and protect sensitive control electronics.
Low power consumption profile utilizing a 24 V DC external supply.
Durable construction optimized for demanding industrial environments.

### Applications

Decentralized drive control in automated packaging machinery.
Conveyor systems and material handling networks.
Automotive assembly lines utilizing DeviceNet or CANopen architectures.
General mechanical engineering applications requiring remote drive parameterization.

### Technical Specifications

Manufacturer	Lenze
Part Number / Model	EMF2175IB
Series	8200-series
Product Type	Fieldbus Communication Module
Supported Protocols	DeviceNet, CANopen
Supply Voltage	24 V DC (±10%)
Current Consumption	Max. 100 mA
Insulation Voltage	270 VAC
Dimensions (W x H x D)	7.60 cm x 7.60 cm x 5.10 cm
Weight	0.10 kg
Commodity Code	85044095
Product Lifecycle Phase	Phase-Out / Legacy Spare Part

### Connections and Interfaces

Interface Type	Function / Description
Inverter Interface	Internal multi-pin connector for direct attachment to the 8200-series drive slot.
Fieldbus Connector	Standardized terminal block for DeviceNet / CANopen network wiring (V-, CAN_L, Shield, CAN_H, V+).

### Installation Guidelines

Ensure the host 8200-series frequency inverter is completely powered down and discharged before installing or removing the module.
Plug the EMF2175IB module firmly into the designated communication slot on the front of the inverter.
Tighten the integrated retaining screws to guarantee reliable grounding and mechanical stability.
Use high-quality shielded twisted-pair cabling compliant with DeviceNet/CANopen specifications to minimize electromagnetic interference.
Install a 120-ohm termination resistor at both physical ends of the network trunk line.

Key Features:

#Fieldbus Modules #Lenze 8200-series

What communication protocols does the Lenze EMF2175IB support?

The EMF2175IB module supports both DeviceNet and CANopen fieldbus protocols for integration with industrial control networks.

What are the power requirements for the EMF2175IB module?

The module operates on an external 24 V DC (±10%) power supply with a maximum current consumption of 100 mA.

Which inverter series is compatible with the EMF2175IB?

It is designed specifically as a communication accessory for the Lenze 8200-series frequency inverters.
