General Electric IC754VSF15CTD QuickPanel operator interfeysi terminali

SKU IC754VSF15CTD

In stock
  • 12-month warranty
  • Free returns within 30 days

  • Manufacturer: General Electric

  • Product No.: IC754VSF15CTD

  • Country of origin:United States

  • Product Type: Operator interfeysi terminali

  • Payment: T/T, Western Union

  • Weight: 800g

  • Dimensions: 19.2 x 13.7 x 3.6 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Tavsif

General Electric IC754VSF15CTD QuickPanel operator interfeysi terminali talabchan avtomatlashtirish boshqaruvi arxitekturalarida yuqori unumdor inson-mashina interfeysi (HMI) sifatida xizmat qilish uchun ishlab chiqilgan ilg‘or, yaxlit sanoat mikrokuteridir. 1 GHz chastotali ARM Cortex A8 protsessori va Microsoft Windows Embedded Compact 7 operatsion tizimida ishlaydigan ushbu operator terminali murakkab sanoat mashinalari bo‘ylab ishonchli vizualizatsiya, real vaqt rejimida ma’lumotlarni qayd etish va uzluksiz aloqa imkonini beradi. U operatorlarga jarayonlarni aniq kuzatish va interaktiv boshqarish imkoniyatlarini taqdim etish uchun boshqaruv konturlariga bevosita integratsiyalanadi.

Proyeksiyalangan sig‘imli multi-touch ekranli yorqin 7 dyuymli keng formatli TFT LCD bilan jihozlangan IC754VSF15CTD yuqori sezgir sensorli navigatsiya, silliq imo-ishora orqali aylantirish va 800x480 WVGA aniqlikdagi tasvirni aniq ko‘rsatishni ta’minlaydi. Tizim xotirasi arxitekturasi 512MB DDR2 SDRAM, qattiq holatdagi virtual qattiq disk vazifasini bajaruvchi 256MB SLC NAND flesh-xotira hamda elektr ta’minoti uzilganda muhim saqlanuvchi ma’lumotlarni himoya qiluvchi batareyali 512KB SRAM xotirasini o‘z ichiga oladi.

Funksiyalar

    800x480 WVGA aniqlikka ega 7 dyuymli proyeksiyalangan sig‘imli multi-touch keng formatli TFT LCD
    Freescale i.MX535 1GHz ARM Cortex A8 yuqori unumdor protsessori
    512MB DDR2 SDRAM tizim xotirasi va 256MB SLC NAND flesh-xotira
    Elektr ta’minotidagi uzilishlar vaqtida saqlanuvchi ma’lumotlarni himoya qilish uchun batareyali 512KB SRAM
    O‘rnatilgan 10/100BaseT Ethernet, RS-232 ketma-ket porti, ikkita USB 2.0 host porti va bitta USB qurilma porti
    Og‘ir sanoat muhitlari uchun mustahkam IP65 va JEM1030 old panel korpusi himoya darajasi

Qo‘llanilishi

    Avtomatlashtirilgan ishlab chiqarish uchastkalarida real vaqt rejimida jarayonlarni vizualizatsiya qilish va operator boshqaruvi
    Qadoqlash, materiallarni tashish va yig‘ish liniyasi uskunalari uchun mashina darajasidagi HMI
    O‘rnatilgan SD karta xotirasi va doimiy xotira orqali ma’lumotlarni qayd etish hamda mahalliy tarixiy tendensiyalarni kuzatish
    O‘rnatilgan HTTP va FTP server imkoniyatlari orqali masofadan monitoring va veb-nashr

Texnik xususiyatlar

Parametr Xususiyat
Brend General Electric
Katalog raqami IC754VSF15CTD
Displey turi LED yoritgichli 7 dyuymli keng formatli TFT LCD
Aniqlik 800 x 480 piksel WVGA
Sensorli ekran Proyeksiyalangan sig‘imli, ikki nuqtali multi-touch
Protsessor Freescale i.MX535 (1 GHz ARM Cortex A8)
Operatsion tizim Microsoft Windows Embedded Compact 7
Tizim xotirasi (RAM) 512 MB DDR2 SDRAM
Saqlash xotirasi (ROM) 256 MB SLC NAND Flash
Saqlanuvchi xotira (SRAM) Batareya zaxirasiga ega 512 KB
Aloqa portlari 1x 10/100BaseT Ethernet (RJ-45), 1x RS-232 ketma-ket port (5 kontaktli), 2x USB 2.0 host, 1x USB 2.0 qurilma
Xotirani kengaytirish 1x SD/SDHC karta uyasi (32 GB gacha qo‘llab-quvvatlaydi)
Kirish quvvat ta’minoti +24 VDC nominal (+24VDC ±20 foiz), maksimal 15W
Ishlash harorati 0°C dan +50°C gacha
Korpus himoya darajasi IP65 va JEM1030 (old panel)
Ishlab chiqarilgan mamlakat Amerika Qo‘shma Shtatlari

Ulanishlar / interfeyslar

    Ethernet porti: 10/100Base-TX tarmoq aloqasini qo‘llab-quvvatlovchi RJ-45 ulagichi
    Ketma-ket port: PLC yoki periferik qurilmalarga bevosita ulanish uchun RS-232 5 kontaktli Euro terminal ulagichi
    Quvvat ulagichi: 24 VDC kirishi va korpus yerga ulanishi uchun 3 kontaktli olinadigan terminal kolodkasi
    Audio interfeyslar: monofonik mikrofon kirishi va stereo liniya chiqishi uchun alohida 3,5 mm raz’yomlar

Muvofiqlik va sertifikatlar

    UL / cUL ro‘yxatidan o‘tgan: UL 60950-1 va CSA C22.2 No. 60950-1
    CE muvofiqligi: Past kuchlanish direktivasi va Elektromagnit moslik direktivasi
    FCC muvofiqligi: 15-qism, A sinfidagi raqamli qurilmalar qoidalari
    RoHS talablariga muvofiq: 2002/95/EC direktivasi
