Beckhoff CP7212-0001-0060 CP72xx Economy Panel PC

Only 10 item(s) left in stock

Manufacturer: BECKHOFF
Product No.: CP7212-0001-0060
Country of origin:Đức
Product Type: Economy Panel PCs
Payment: T/T, Western Union
Weight: 5000g
Shipping port: Xiamen
Warranty: 12 months

Description

Designed for mounting arm installation in demanding manufacturing environments, the CP7212-0001-0060 Panel PC combines a high-resolution 15-inch display control panel with an integrated high-performance industrial PC. This Economy Panel PC is housed in a rugged, fully enclosed IP65-rated aluminum housing, providing direct-at-the-machine operation without requiring a control cabinet. Equipped with a 3.5-inch motherboard and a dual-core Intel processor, the system is engineered to run TwinCAT automation software and process-intensive HMI applications efficiently.

Features

Rugged Enclosure: Full aluminum housing providing complete dust and water jet protection rated to IP65.
Mounting Compatibility: Equipped with a rotatable mounting arm adapter suitable for Rittal and Rolec 48 mm diameter top-entry suspension tube systems.
Thermal Management: Efficient passive cooling via an external heat sink structure, assisted by an internal fan to distribute heat uniformly across the housing walls.
Sizable Storage Options: Features dedicated internal slots for one 2.5-inch hard disk or SSD and one CFast card.
Reliable Connectivity: Built-in dual 100/1000BASE-T Ethernet interfaces with support for push-pull industrial connection standards.
Integrated RAID: On-board SATA RAID 1 controller for system redundancy and operational data security.

Applications

Operator interface and control terminal for machinery automation.
Process visualization and monitoring in food, chemical, and pharmaceutical plants.
Automated assembly and manufacturing line control stations.
Suspended mounting control stations in automotive and metalworking facilities.

Technical Specifications

Manufacturer	Beckhoff
Model/Part Number	CP7212-0001-0060
Device Type	Economy Panel PC
Display Size	15-inch
Resolution	1024 x 768
Processor	Intel Celeron G3900TE (2.3 GHz, 2 Cores)
Memory	4 GB DDR4 RAM
Motherboard	3.5-inch motherboard (6th/7th Gen Intel Core/Celeron platform)
Primary Storage	320 GB 2.5-inch Hard Disk Drive
Storage Slots	1 x 2.5-inch HDD/SSD slot, 1 x CFast slot
Network Interfaces	2 x 100/1000BASE-T (one led out via push-pull)
Storage Controller	On-board SATA RAID 1
Input Voltage	24 V DC
Protection Rating	IP65
Operating Temperature	0 to 45 degC
Housing Material	Aluminum
Shipping Weight	5 kg

Connections and Interfaces

Interface Type	Specification / Connectivity
Ethernet Port	1 x Ethernet 100/1000BASE-T push-pull connection
Power Supply Connection	1 x 24 V DC terminal input
Auxiliary Interface Space	Up to 6 IP65 connectors (includes 4 free accessory ports)

Installation Guidelines

Mounting: Attach to a compatible Rittal or Rolec mounting arm using the integrated rotatable adapter for 48 mm tubes. Ensure all fasteners are torqued to spec.
Cooling Clearance: To allow adequate passive convection cooling, maintain at least 20 cm (7.9 inches) of free air space around all sides of the Panel PC.
Wiring: Route cables through the protective tube of the mounting arm directly into the IP65 sealed wiring area. Ensure unused connector glands are fully sealed with IP65-rated blanks.

Key Features:

#CP72xx Series #Economy Panel PCs

What mounting systems are supported by the CP7212-0001-0060?

It is equipped with a rotatable mounting arm adapter designed to interface with Rittal and Rolec suspension systems using a 48 mm diameter tube connected from the top.

Does this Panel PC require forced-air ventilation inside a cabinet?

No. The CP7212-0001-0060 uses passive heat sinks combined with an internal fan to distribute heat evenly across its aluminum walls. However, it requires 20 cm (7.9 inches) of free space around the unit for external air circulation.

What is the ingress protection rating of the CP7212-0001-0060?

The Panel PC has a protection rating of IP65, making it completely dust-tight and protected against water jets from any direction when all connections are properly mated.

Does this unit support SSD upgrades or RAID configurations?

Yes, it contains one slot for a 2.5-inch hard disk or SSD, one slot for a CFast card, and features an integrated on-board SATA RAID 1 controller.
