Omron V680-HS63-W 2M V680 Series RFID Square Antenna

Omron V680-HS63-W 2M V680 Series RFID Square Antenna

Only 2 item(s) left in stock

  • Manufacturer: Omron

  • Product No.: V680-HS63-W 2M

  • Country of origin:Nhật Bản

  • Product Type: RFID Antennas

  • Payment: T/T, Western Union

  • Weight: 850g

  • Dimensions: 4 x 5.3 x 2.3 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Xem toàn bộ chi tiết
Mô tả sản phẩm
FAQ
Vận chuyển và Trả hàng
Chi tiết bổ sung
Đánh giá

Description

Designed for industrial RFID applications, the Omron V680-HS63-W 2M square antenna features a detachable amplifier unit design to optimize electromagnetic read/write processes in harsh manufacturing environments. This sensor-head-style RFID antenna operates within the high-performance V680 series system, providing reliable data transmission when paired with compatible V680 amplifier units and controllers. The integrated 2-meter standard cable features a waterproof connector construction to maintain signal integrity in moisture-prone industrial setups.

Features

  • Square configuration designed for space-efficient mounting in tight industrial environments.
  • Detachable amplifier unit design facilitates modular maintenance, troubleshooting, and configuration.
  • Standard 2-meter connection cable with a high-reliability waterproof connector.
  • Robust mechanical housing offering superior shock and vibration resistance.
  • High-level environmental protection suitable for demanding industrial deployments with fluid exposure.

Applications

  • Automated assembly lines and industrial conveyor routing systems.
  • Automotive manufacturing powertrain and chassis tracking.
  • Warehouse logistics and automated pallet identification systems.
  • Tool identification and management systems in CNC machining centers.

Technical Specifications

Manufacturer Omron
Part Number / Model V680-HS63-W 2M
Series V680 Series RFID System
Antenna Type Square, Detachable Amplifier Unit Type
Cable Length 2 meters
Cable Type Standard cable with waterproof connector
Ambient Operating Temperature -10 degC to 60 degC (with no icing)
Ambient Storage Temperature -25 degC to 75 degC (with no icing)
Ambient Operating Humidity 35% to 95% (with no condensation)
Insulation Resistance 20 MOhm min. (at 500 VDC) between the cable terminals and the case
Dielectric Strength 1000 VAC (50/60 Hz) for 1 minute between the cable terminals and the case with a current leakage of 5 mA max.
Degree of Protection IP67 (IEC 60529:2001); Oil resistance equivalent to IP67G (JIS C 0920:2003, Appendix 1) (Antenna portion)
Shock Resistance 500 m/s2 in X, Y, and Z directions 3 times each (18 times total)
Dimensions 4 x 5.3 x 2.3 cm
Weight 0.85 kg

Installation Guidelines

  • Mounting: Secure the antenna on a flat surface using appropriate mounting brackets to avoid physical deformation and mechanical stress.
  • Metal Interference: Ensure the recommended non-metallic clearance zones around the antenna head are maintained to prevent electromagnetic field attenuation and read/write range reduction.
  • Cable Routing: Do not exceed the minimum bend radius of the 2-meter cable. Route the RF cabling separately from high-voltage power lines to minimize electromagnetic interference (EMI).
  • Connector Integrity: Ensure that the waterproof connector is fully threaded and tightened to maintain the rated IP67/IP67G protection standards.

Compliance and Certifications

  • IEC 60529:2001 (IP67 compliance)
  • JIS C 0920:2003, Appendix 1 (IP67G oil resistance compliance for the antenna portion)
Key Features:
#Omron V680 Series #RFID Antennas

What is the IP rating of the Omron V680-HS63-W 2M antenna?
The antenna portion of the V680-HS63-W 2M has an IP67 protection rating according to IEC 60529:2001, and oil resistance equivalent to IP67G under JIS C 0920:2003.

Can the amplifier unit be detached from this antenna model?
Yes, the V680-HS63-W 2M is a detachable amplifier unit type, allowing the square antenna and amplifier to be modularly separated or replaced during maintenance.

What are the temperature limits for operating this antenna?
The ambient operating temperature range is -10 degC to 60 degC with no icing, and the ambient storage temperature range is -25 degC to 75 degC with no icing.
