Allen-Bradley 2711P-T6M5D8 PanelView Plus 6 600 Bedienerterminal

Description

The Allen-Bradley 22B-A8P0N104 (Correction: 2711P-T6M5D8) is a digital human-machine interface device configured as part of the PanelView Plus 6 600 control platform to provide local visualization and technical command capabilities across automated manufacturing loops. This industrial station houses a 5.7-inch Grayscale TFT LCD display that provides a viewing dimension of 115 x 86 mm (4.5 x 3.4 in.) at a digital resolution of 320 x 240 pixels with a 16-level gray matrix. Operator interface interaction is executed via an integrated 4-wire analog resistive touchscreen designed for up to 1 million actuations under a mechanical activation force spectrum of 10 to 100 grams. Intended for local serial communication links, the device incorporates a built-in RS-232 connection interface executing point-to-point data mapping over a maximum operational line length of 15 meters using DF1 or DH-485 automation protocols. System resources utilize 256 MB of RAM alongside 512 MB of non-volatile storage, which can be expanded through an integrated Secure Digital (SD) card slot supporting 1784-SD1 and 1784-SD2 flash storage modules.

Features

• Integrated 4-wire analog resistive touchscreen architecture supporting direct on-screen command interaction.
• Embedded RS-232 communication terminal infrastructure optimized for point-to-point processing layouts.
• Dedicated USB host and device peripheral ports for alternative hardware interface management like mouse or keyboard tracking.
• Expandable non-volatile memory layout utilizing an onboard Secure Digital slot.
• Fixed ten-key function pad mapping (F1-F10) for localized command entry loops.
• Integrated real-time internal clock circuit with backup battery power implementation.

Applications

• Operator control stations for standalone industrial machinery automation lines.
• Point-to-point supervision setups utilizing localized DF1 or DH-485 controllers.
• Specialized material monitoring lines requiring clean grayscale status visualization.

Technical Specifications

General Specifications

Performance and Display

Power and Memory

Communication and Interfaces

Mechanical Data

Installation Guidelines

• Align the terminal housing carefully when executing panel cutout installation layouts to preserve correct panel-mounting pressure parameters.
• Connect a stable direct current source matching the 18-30 VDC power boundary conditions to protect internal processor rails.
• Ensure serial line pathways utilize the specified 2711-NC13 communication cable link and do not exceed the structural 15-meter length limit.
• Avoid mechanical vibration stress fields during mounting execution to protect the resistive touchscreen calibration curves.
