Schneider Modicon Premium TSXAEY810C Analog-Eingangsmodul

Description

The TSXAEY810C is a high-precision analog input module developed for the Modicon Premium automation platform. This module features 8 low-level input channels capable of handling both current and voltage signals. With an integrated 16-bit resolution, it provides the high-fidelity signal conversion necessary for complex process monitoring and control tasks. Designed to act as a reliable interface between sensitive field instrumentation and the PLC CPU, the TSXAEY810C is a standard choice for industrial applications requiring accurate measurement and rapid data acquisition.

Features

• Multi-Signal Support: Configurable for either current or voltage input signals.
• High Resolution: 16-bit A/D conversion for superior measurement accuracy.
• Channel Density: 8 isolated channels for simultaneous process monitoring.
• Modicon Premium Compatibility: Native design for seamless integration with Premium PLC backplanes.
• Industrial Durability: Engineered to perform consistently in demanding industrial environments.

Applications

• Precision process control (e.g., pressure, flow, and temperature monitoring).
• High-accuracy data acquisition systems.
• Industrial laboratory or test stand automation.
• Feedback loop management in complex manufacturing machinery.

Technical Specifications

Installation Guidelines

• Module Seating: Ensure the module is properly aligned with the rack guide rails and fully seated to guarantee a stable electrical connection to the backplane.
• Wiring and Shielding: Always use shielded, twisted-pair cabling for analog signals to minimize the impact of electromagnetic interference (EMI). Ground the shields at the PLC cabinet side only, unless otherwise specified by the system design.
• Configuration: Use the PLC programming software to configure the specific input range (current or voltage) for each channel to avoid signal mismatch.
• Calibration: Periodically verify the analog measurement accuracy against a known reference source to maintain process precision.
• Environment: Ensure the control cabinet provides adequate ambient cooling, as high temperatures can influence the accuracy of high-resolution analog measurements.
