Schneider Modicon Premium TSXRKY4EX Erweiterbares Rack

Description

The TSXRKY4EX is a 4-slot extendable rack designed for the Modicon Premium automation platform. This hardware is specifically engineered to support multi-rack configurations, allowing for the modular expansion of PLC system architectures. By providing a secure mechanical and electrical foundation, the rack allows for the installation of processors, I/O modules, and communication units in complex industrial control systems. With an IP20 ingress protection rating, it is ideal for installation within standard industrial enclosures, serving as a reliable interface for scaling automation deployments.

Features

• Multi-Rack Scalability: Designed for complex systems requiring secondary or tertiary rack expansion.
• 4-Slot Capacity: Provides a compact mounting footprint for essential Modicon Premium modules.
• Robust Mechanical Design: Offers a stable foundation for module interlinking and internal bus connections.
• IP20 Protection: Suitable for use in protected indoor industrial environments.
• Seamless Integration: Fully compatible with the Modicon Premium modular hardware ecosystem.

Applications

• Modular process automation systems.
• Multi-rack PLC system architectures.
• Compact machine control requiring scalable I/O.
• Industrial facilities utilizing distributed control hardware.

Technical Specifications

Installation Guidelines

• Mounting: Secure the rack to a grounded metallic backplane within an enclosure to ensure structural stability and maintain EMI immunity.
• Bus Connection: Ensure that the communication bus cabling is fully seated and locked into the rack connectors when extending to additional racks; check for proper seating to avoid communication faults.
• Grounding: Ensure the rack's protective earth terminal is connected to the cabinet’s main ground bus for safety and to reduce electrical noise.
• Module Insertion: Use the integrated guide rails for module installation; ensure each module is fully seated and screws are tightened to maintain a consistent connection with the backplane bus.
• Environment: Install in an environment free from excessive dust and moisture; while the rack is robust, the electrical bus contacts are sensitive to environmental pollutants.
