Siemens 6AV7894-0AD10-1AB2 SIMATIC HMI IPC677C Panel PC

Only 2 item(s) left in stock

Manufacturer: Siemens
Product No.: 6AV7894-0AD10-1AB2
Country of origin:Deutschland
Product Type: Panel PC
Barcode: 85371091
Payment: T/T, Western Union
Weight: 17450g
Dimensions: 67.00 x 55.00 x 28.00 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Siemens 6AV7894-0AD10-1AB2 is a SIMATIC HMI IPC677C Panel PC designed for industrial visualization and control applications. This robust Panel PC integrates a 19-inch touch display with a 1280x1024 resolution, providing a clear and interactive operator interface. It features a Core I3-330E processor, 2 GB DDR3 RAM, and a 250 GB SATA HDD, making it suitable for demanding industrial environments. Connectivity options include dual Gigabit Ethernet ports, multiple USB V2.0 interfaces (including a front-side USB interface), and a serial COM1 port. The unit also incorporates a watchdog, temperature, and fan monitoring, alongside an onboard RAID controller for enhanced reliability. It operates on a 24 V DC power supply and comes pre-installed with Windows XP Professional SP3.

Features

Integrated 19-inch Touch Display (1280x1024 resolution)
Core I3-330E Processor (2C/4T, 2.13 GHz, HT, VT, 3 MB cache)
2 GB DDR3 1066 DIMM RAM
250 GB SATA Hard Disk Drive
DVD+-R+-RW Optical Drive
2x 10/100/1000 Mbit/s Ethernet Ports
4x USB V2.0 Ports (plus front-side USB interface)
1x Serial Port (COM1)
Onboard Watchdog, Temperature, and Fan Monitoring
Integrated RAID Controller
2x Free PCI Expansion Slots
Pre-installed Windows XP Professional SP3 MUI
Includes SIMATIC IPC Image & Partition Creator V3.4
24 V DC Power Supply

Applications

The Siemens SIMATIC HMI IPC677C Panel PC is suitable for a wide range of industrial automation applications requiring local HMI functionality and PC-based control. Typical deployments include:

Machine operation and visualization
Process control and monitoring systems
Data acquisition and logging
Manufacturing execution systems (MES) interfaces
Building automation control panels
Industrial workstation for SCADA systems

Technical Specifications

Parameter	Value
Brand	Siemens
Manufacturer	Siemens
Range	Simatic Panel PC
Subrange	IPC677C
Type of Product	PC panels
PLM Product Phase	Phase-Out
Display Type	19" Touch
Display Resolution	1280x1024
Processor	Core I3-330E (2C/4T, 2.13 GHz, HT, VT, 3 MB cache)
RAM	2 GB DDR3 1066 DIMM
Storage	250 GB HDD SATA
Optical Drive	DVD+-R+-RW
Ethernet Ports	2x 10/100/1000 Mbit/s
USB Ports	4x USB V2.0 (plus front-side USB interface)
Serial Port	1x (COM1)
Expansion Slots	2x PCI free
Operating System	Windows XP Prof. SP3 MUI (de, en, fr, es, it)
Included Software	SIMATIC IPC Image & Partition Creator V3.4
Power Supply	24 V DC
Package Dimensions (Calculated)	67.00 x 55.00 x 28.00 cm
Shipping Weight	17.45 kg
Commodity Code	85371091
Export Control Regulations (ECCN)	5A992
Country of Origin	Germany

Key Features:

#IPC677C #Panel PC

What operating system is pre-installed on the 6AV7894-0AD10-1AB2?

The Panel PC comes with Windows XP Professional SP3 MUI (Multi-User Interface) pre-installed, supporting German, English, French, Spanish, and Italian languages.

What type of display does this Panel PC feature?

It features a 19-inch touch display with a resolution of 1280x1024 pixels, suitable for HMI applications.

What are the primary connectivity options?

The unit includes two 10/100/1000 Mbit/s Ethernet ports, four USB V2.0 ports (plus a front-side USB interface), and one serial (COM1) port.

Does the IPC677C have internal monitoring features?

Yes, it includes an onboard watchdog, temperature monitoring, and fan monitoring to ensure reliable operation in industrial environments.

What is the power supply requirement for this Panel PC?

The Siemens 6AV7894-0AD10-1AB2 requires a 24 V DC power supply.
