ABB SPDSO14 Symphony Plus Digital Output Module

فقط 5 قلم(های) کالا در انبار باقی مانده است

تولیدکننده: ABB
شماره محصول: SPDSO14
کشور سازنده:هند
نوع محصول: Digital Output Module
بارکد: 85389081
پرداخت: حواله بانکی (T/T)، وسترن یونیون
وزن: 850g
ابعاد: 73.66 mm x 360.68 mm x 279.4 mm
بندر حمل و نقل: شیامن
گارانتی: ۱۲ ماه

The ABB SPDSO14 is a high-density Digital Output Module engineered for the Symphony Plus control system architecture. Operating within the HR Series (Harmony Rack) I/O range, this module provides 16 independent output channels configured as an open collector circuit design. It serves as a critical interface for driving field devices such as interposing relays, solenoids, indicators, and status inputs in rugged industrial automation environments.

Features

16 Digital Output Channels: High-density rack-mounted design maximizes control loop capacity within standard enclosure profiles.
Open Collector Configuration: Provides flexible external circuit integration, allowing loop voltages to match field device demands.
Symphony Plus Compatibility: Full native integration with Harmony Rack systems ensures high-speed backplane communications and diagnostics.
Compact Form Factor: Optimizes cabinet space while adhering to precise thermal dissipation and mechanical locking standards.

Applications

Power generation plants (boiler controls, turbine auxiliaries, and balance of plant signaling).
Water and wastewater treatment distribution networks and pump controls.
Petrochemical and refining processing sequence controls and interlocking systems.
General heavy industrial process automation requiring reliable open-collector digital switching.

Technical Specifications

Manufacturer	ABB
ABB Type Designation	SPDSO14
Channel Type	DO (Digital Output)
Number of Output Channels	16
Output Circuit Design	Open Collector
Product Net Depth / Length	73.66 mm
Product Net Height	360.68 mm
Product Net Width	279.4 mm
Product Net Weight	0.85 kg (Calculated)
Package Dimensions	410 mm x 320 mm x 110 mm (Calculated)
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm)
HS Code / Customs Tariff	85389081
Country of Origin	India

Installation Guidelines

CRITICAL WARNING: Isolate all external loop power supplies and de-energize the rack mounting backplane prior to card insertion or extraction. Failure to remove external loop voltage from open collector connections can result in accidental switching, module failure, or unpredictable field device activation.

Verify that the target subrack slot matches the digital output configuration defined in the Symphony Plus control strategy software.

Align the card edge carefully with the top and bottom guides of the Harmony Rack, then push firmly until the module is completely seated in the backplane connector.

Secure the module using the integral faceplate retaining fasteners to ensure robust grounding and vibration immunity.

Attach the termination unit wiring and apply external circuit power only after verifying load impedance specifications.

Product Image	Model Number / Title	Condition	Availability	Action
	ماژول افزونه EtherCAT خروجی دیجیتال 16 کاناله BECKHOFF EJ2889	Original New	In Stock	View Details
	ترمینال خروجی دیجیتال ۸ کاناله BECKHOFF مدل EL2878-0005 با اتصال کابل روبانی	Original New	In Stock	View Details

Key Features:

#Digital Output Module #Symphony Plus

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What is the primary function of the open collector outputs on this module?

The open collector configuration acts as a solid-state switch to ground. It requires an external power supply and external load resistance, giving you flexibility in selecting different operating voltages for varied field devices.

Does this unit provide isolation between the individual output channels?

Open collector modules in this family typically share a common return path within the card or block grouping. Refer to your specific Symphony Plus termination unit wiring diagram to verify shared commons vs individual group isolation boundaries.

What happens to the outputs if the control system backplane communication fails?

The module enters a predefined failsafe state determined by its hardware configuration or system software parameters, which typically drops the open collector transistors into an open (off) condition to safely de-energize external loads.
