BECKHOFF CP7901-0001-0000 CP7901 Series Economy Control Panel

Description

Designed for direct machine-level integration, the BECKHOFF CP7901-0001-0000 serves as a rugged industrial display and operating medium featuring a 12-inch screen with an 800 x 600 resolution. This CP7901 series Economy Control Panel utilizes specialized connection technology, transmitting signals via DVI-E and USB-E 2.0 to allow operating distances of up to 50 meters from the industrial PC. Housed in a durable aluminum casing with IP65 protection, it is engineered to withstand demanding industrial environments.

Features

• 12-inch color TFT display offering an 800 x 600 resolution.
• Integrated DVI-E and USB-E 2.0 connection technology for distances up to 50 meters from the control computer.
• Robust IP65-rated housing provides high resistance against dust, debris, and water jets.
• Equipped with a single-finger analog resistive touch screen for intuitive operator control.
• Sturdy aluminum enclosure designed to withstand continuous industrial operation.
• Compatible with standard DVI output signals on the PC side.

Applications

• Industrial manufacturing and assembly line visualization.
• Power generation and process control monitoring.
• Heavy machinery and mechanical engineering HMI stations.
• Oil and gas monitoring interfaces.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mount the Control Panel using the 4 M6 x 18 mm threaded holes located on the rear backplane adapter.
• Ensure the integrated IP65 sealing is properly aligned and secured to protect against fluid ingress.
• Limit total cable run lengths for DVI-E and USB-E 2.0 connections to a maximum of 50 meters to maintain signal integrity.
• Ensure adequate clearance around the aluminum enclosure to facilitate passive thermal dissipation.
