Bently Nevada 330101-00-55-20-12-05 3300 XL 8 mm Proximity Probe

Description

Option 12 (ClickLoc connector with FluidLoc cable) and Option 55 (5.5-inch overall case length) specify this 3300 XL 8 mm proximity probe configuration — 330101-00-55-20-12-05. This configuration utilizes a 3300 XL 8 mm proximity probe with a 3/8-24 UNF thread, no unthreaded length (Option 00), 2.0 meters of total lead length (Option 20), and CSA, ATEX, and IECEx agency approvals for hazardous environments (Option 05).

Unlike standard coaxial cable variants, the integrated FluidLoc cable is designed to prevent process oil, moisture, and other industrial lubricants from migrating out of the machine casing through the interior of the probe cable. Operating on the eddy-current measurement principle, the probe provides non-contact displacement and shaft vibration data, pairing with a standard 3300 XL Proximitor sensor and extension cable to interface with Bently Nevada 3500 monitoring systems.

Features

• Option 12 FluidLoc cable prevents lubricant and process fluid bypass through the interior conductor path.
• Option 00 unthreaded length (0.0 inches) provides a fully threaded probe casing for versatile mounting positioning.
• Option 55 overall case length of 5.5 inches provides deep reach into bearing blocks and mechanical housings.
• Option 20 provides 2.0 meters (6.6 feet) of integrated probe lead length.
• Option 05 designates CSA, ATEX, and IECEx hazardous area certifications.
• Gold-plated ClickLoc connector provides secure coaxial connections with finger-tight force and no special tools.

Applications

• Steam and gas turbine shaft vibration and axial position measurement.
• Compressor and pump rotor displacement monitoring.
• Industrial rotating machinery protection in high-oil or high-lubricant environments.
• Permanent installations requiring certified safety in hazardous locations.

Ordering Information

Technical Specifications

Connections and Interfaces

Compliance and Certifications

• CSA (Class I, Div 1, Groups A, B, C, D)
• ATEX (Ex ia IIC T5...T1 Ga)
• IECEx (Ex ia IIC T5...T1 Ga)
• CE Compliant
