Bently Nevada 3500/94M-05-00 3500 Series VGA Display Module

Description

Designed for industrial-grade machinery protection and real-time visualization, the 3500/94M-05-00 serves as an integral interface module within the Bently Nevada 3500 Series machinery monitoring rack. This module transmits essential monitoring parameters and configuration data directly to localized display panels, allowing plant operators to view critical vibration levels, phase angles, and alarm statuses on-site without requiring access to a separate control station workstation.

The 3500/94M-05-00 configuration features a 15-inch display formatted for seamless integration into standard 19-inch rack enclosures. It is optimized to deliver consistent, low-latency video feeds directly from the rack backplane. Note that this specific legacy module version has been succeeded by the regional variation 3500/94M-05-00-CN, which serves as a compatible direct replacement depending on localized compliance standards.

Features

• Provides high-fidelity, real-time VGA visualization of dynamic machinery protection parameters directly at the cabinet level.
• Includes a 15-inch display unit designed to fit standard industrial 19-inch racks.
• Option 00 configuration eliminates unnecessary KVM routing cables when integrated into simplified local network structures.
• Supports multi-channel visualization options for efficient machinery diagnostic overviews.
• Engineered with rugged hardware components suited for constant operation in harsh industrial environments.

Applications

• Power generation facilities (monitoring steam and gas turbine systems).
• Petrochemical and oil refining operations.
• Heavy industrial processing plants requiring continuous localized cabinet readouts.
• Compressor and pump protection systems.

Ordering Information

Technical Specifications

Installation Guidelines

• Ensure all power to the 3500 system rack is disconnected before inserting or removing the 3500/94M display module interface card.
• Install the 15-inch display panel into a standardized 19-inch rack space, utilizing the provided mounting holes to prevent vibration-induced strain.
• Ensure that cabinet ventilation is sufficient to keep ambient temperatures around the display unit within standard operating limits.
• Route all VGA and signal interfaces away from high-voltage AC electrical lines to avoid signal interference.
