استارتر نرم آلتیاستارت 46 اشنایدر الکتریک ATS46C32N

Description

The Schneider Electric ATS46C32N is a soft starter from the Altistart 46 range, designed for controlled starting and stopping of three-phase AC induction motors. This unit is rated for a continuous current of 320 A and supports a maximum operational voltage of 500 V. It is engineered to reduce mechanical stress on drive systems and minimize inrush current during motor startup. The device features compatibility with TeSys D and F-line contactors, providing a flexible solution for high-power motor control applications.

Features

• Smooth acceleration and deceleration for three-phase motors
• Rated current: 320 A
• Maximum voltage: 500 V
• Power ratings: 100 HP @ 208 V, 125 HP @ 230 V, 250 HP @ 460 V
• Compatible with TeSys D and F-line contactor series

Applications

• High-power industrial pump and fan systems
• Conveyor belt start-up control
• Compressor motor soft starting
• Large-scale industrial machinery acceleration

Technical Specifications

Installation Guidelines

• Mounting: Ensure the soft starter is mounted in a vertical position within an adequately ventilated enclosure to dissipate heat generated during operation.
• Clearance: Follow the manufacturer's specified spacing requirements above and below the unit to prevent thermal faults.
• Grounding: Connect the soft starter chassis to a common protective earth bus to maintain electromagnetic compatibility and safety.
• Wiring: Use appropriately sized power cables and ensure all terminal connections are torqued to specifications to prevent overheating.
• Contactors: When using with TeSys D or F-line contactors, verify the correct wiring configuration for the bypass or isolation setup as required by the application.
