دکمه فشاری دو سر مدل ZB4BW7A17147 از اشنایدر الکتریک

Description

The Schneider Electric ZB4BW7A17147 is a double-headed push-button with pilot light, featuring a black bezel for use in industrial control panels. This control unit is designed to provide dual switching functions within a single mounting space, streamlining operator interfaces in machinery and electrical cabinets. The integrated pilot light provides clear visual status indication, ensuring reliable human-machine interaction in demanding industrial environments.

Features

• Dual-button configuration for space-saving installation
• Integrated pilot light for status monitoring
• Black bezel construction for durability and aesthetics
• Standardized mounting for integration into control consoles

Applications

• Industrial machinery control panels
• Automation system operator stations
• Electrical distribution equipment interfaces
• Process control monitoring systems

Technical Specifications

Installation Guidelines

• Panel Mounting: Secure the unit in a standard circular cutout according to the mechanical dimensions specified for the ZB4 range.
• Wiring: Ensure correct termination of the pilot light and switch contacts to prevent short circuits.
• Environmental Sealing: Verify that the seal is properly seated to maintain the required ingress protection rating against dust and moisture.
• Tightening: Use appropriate tools to tighten the locking ring to ensure the bezel remains fixed during vibration.
