زیمنس 6AV3515-1MA22-1AA0 | کوروس HMI | پنل اپراتور سری OP15

Description

The 6AV3515-1MA22-1AA0 is a Coros HMI OP15/C2 operator panel designed for machine-level control and process visualization. This interface unit supports flexible display configurations, offering either a 4-line, 20-character-per-line format or an 8-line, 40-character-per-line mode, depending on the application requirements. Equipped with 256 KB of user memory and 8 programmable softkeys, the 6AV3515-1MA22-1AA0 enables operators to manage automation tasks and monitor system status with high efficiency. The panel utilizes multiple communication interfaces, including 2x TTY/V.24 and 1x MPI/PPI/L2-DP, allowing for seamless connectivity within legacy Siemens control architectures. This hardware is categorized as discontinued; for new projects, the manufacturer recommends utilizing the OP17 series.

Features

• Dual display mode: 4 lines (20 CPL) or 8 lines (40 CPL)
• 8 programmable softkeys for intuitive operator input
• 256 KB integrated user memory for project data
• Versatile communication ports: 2x TTY/V.24 and 1x MPI/PPI/L2-DP
• Robust industrial design for panel mounting
• Compact dimensions suitable for standard control enclosures

Applications

• Human-Machine Interface (HMI) for PLC-based automation
• Machine status monitoring and alarm management
• Parameter entry and process setpoint adjustment
• Integration in legacy Siemens S5/S7 control systems
• Industrial manufacturing process control

Technical Specifications

Installation Guidelines

• Panel Mounting: The device is designed for flush mounting in a control panel cutout. Ensure the gasket is properly seated to maintain the required protection rating.
• Grounding: Always connect the functional ground terminal to the system earth to ensure electromagnetic compatibility and user safety.
• Communication Cables: Use specified shielded cables for TTY/V.24 and MPI/DP connections to prevent signal interference from industrial noise.
• Environment: Protect the rear of the device from excessive heat, conductive dust, and vibration within the enclosure.
• Programming: Configuration of the operator panel requires the appropriate legacy HMI programming software supported by the OP15 series.
