Siemens 6AV6542-0AC15-2AX0 SIMATIC MP270 Multi Panel

Only 6 item(s) left in stock

Manufacturer: Siemens
Product No.: 6AV6542-0AC15-2AX0
Country of origin:آلمان
Product Type: Multi Panel
Barcode: 85371091
Payment: T/T, Western Union
Weight: 6g
Dimensions: 48.00 x 31.00 x 5.00 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Siemens 6AV6542-0AC15-2AX0 is a SIMATIC MP270 Multi Panel, featuring a 10-inch STN display for clear visualization in industrial environments. This HMI panel is equipped with 12 MB Flash-EPROM and 32 MB RAM, providing reliable data storage and smooth operation for production line controls. The 6AV6542-0AC15-2AX0 is configurable using ProTool software from version V5.2+SP2, offering flexibility for integration into existing automation systems. Its robust design and dependable performance ensure suitability for continuous use in demanding industrial settings, making it a practical choice for upgrading or replacing legacy HMI solutions.

Features

10-inch STN display
12 MB Flash-EPROM for program and data storage
32 MB RAM for operational data
Configurable with ProTool software (V5.2+SP2 or higher)
Key-operated interface
Designed for industrial environments

Applications

Human-Machine Interface (HMI) for industrial machinery
Visualization and control in production lines
Integration into existing automation systems
Monitoring and operation in demanding industrial settings
Upgrade or replacement for legacy HMI systems

Technical Specifications

Attribute	Value
Brand	Siemens
Manufacturer	Siemens
Range	SIMATIC HMI
Subrange	Multi panels 270 series
Product Type	Multi Panel
Supply Voltage	24V DC
Product Phase	Obsolete
Predecessor	6AV6542-0AE15-2AX0
Screen Diagonal	10.4" inch
Display Type	STN
Display Resolution	640 x 480 pixels
Type of Operation	Keys
Display Colors	12288
Flash-EPROM	12 MB
RAM	32 MB
Package Dimensions	48.00 x 31.00 x 5.00 cm
Shipping Weight	6.00 kg
Commodity Code	85371091
Export Control Regulations (ECCN)	N

Installation Guidelines

De-energize System: Ensure all power to the control cabinet and associated equipment is disconnected before beginning installation.
Mounting: Mount the Multi Panel into a prepared panel cutout. Secure the unit using the provided mounting clamps or screws to ensure a stable fit.
Power Connection: Connect the 24V DC supply voltage to the designated power terminals, observing correct polarity. Ensure the power source is stable and within the specified voltage range.
Grounding: Connect the panel's protective earth (PE) terminal to the cabinet's ground bus for safety and electromagnetic compatibility.
Communication Connections: Connect any necessary communication cables (e.g., MPI, PROFIBUS, Ethernet if applicable) to the respective ports on the panel and the automation system.
Configuration: Once physically installed and powered, configure the panel using ProTool software (V5.2+SP2 or higher) to load the application project.
Functional Test: After configuration, perform a comprehensive functional test to verify correct operation of the HMI and its interaction with the connected automation system.

Key Features:

#Multi Panel #SIMATIC HMI

What is the display type and size of the 6AV6542-0AC15-2AX0?

The panel features a 10.4-inch STN display with a resolution of 640 x 480 pixels and 12288 display colors.

What software is required to configure this Multi Panel?

The Siemens 6AV6542-0AC15-2AX0 is configurable using ProTool software from version V5.2+SP2 or higher.

What are the memory specifications for this device?

It includes 12 MB of Flash-EPROM for program and data storage, and 32 MB of RAM for operational data.

What is the required supply voltage?

The Multi Panel operates on a 24V DC supply voltage.
