Siemens 6AV7881-3AE00-2BA0 SIMATIC IPC277D Nanopanel PC

Only 8 item(s) left in stock

Manufacturer: Siemens
Product No.: 6AV7881-3AE00-2BA0
Country of origin:آلمان
Product Type: Nanopanel PC
Barcode: 85371098
Payment: T/T, Western Union
Weight: 3400g
Dimensions: 18.50 x 18.50 x 15.00 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Siemens 6AV7881-3AE00-2BA0 is a SIMATIC IPC277D Nanopanel PC designed for robust operation in industrial automation environments. This model integrates a 12-inch touch TFT display, providing intuitive user interaction and clear visualization for various process monitoring and control applications. Powered by an Intel Atom E660 processor operating at 1.3 GHz and equipped with 2 GB RAM, it delivers reliable performance for demanding production settings. Connectivity is flexible, featuring two Gigabit Ethernet RJ45 ports, three high-current USB 2.0 ports, and a serial COM1 interface, facilitating straightforward integration into diverse system architectures. Storage is managed via a CompactFlash slot, which includes a pre-installed 4 GB CompactFlash card and supports SSD options. The system runs on Windows Embedded Standard 2009 SP3, ensuring compatibility with a wide range of industrial applications. Operating on a 24 V DC power supply, the unit is supplied without pre-installed SIMATIC software, allowing for customization to specific project requirements. The 6AV7881-3AE00-2BA0 is engineered for long-term reliability and low maintenance within industrial production environments.

Features

12-inch Touch TFT Display
Intel Atom E660 (1.3 GHz) Processor
2 GB RAM
2x 10/100/1000 Mbps Ethernet (RJ45) Ports
3x USB V2.0 Ports (High Current)
1x Serial (COM1) Interface
CompactFlash Slot (with 4 GB CF pre-installed)
Windows Embedded Standard 2009 SP3 Operating System
24 V DC Power Supply
Designed for Industrial Automation Environments

Applications

Human-Machine Interface (HMI) for process visualization and control
Embedded control systems in manufacturing and production lines
Data acquisition and monitoring in industrial settings
Operator panels for machinery and equipment
Distributed control systems requiring local computing power

Technical Specifications

Brand	Siemens
Manufacturer	Siemens
Product Range	SIMATIC Panel PC
Product Subrange	IPC277D
Product Type	Nanopanel PC
Display Type	Touch TFT
Display Size	12 inch
Processor	Intel Atom E660
Processor Speed	1.3 GHz
RAM	2 GB
Operating System	Windows Embedded Standard 2009 SP3
Storage Type	CompactFlash slot (supports CF 2 GB or more/SSD)
Pre-installed Storage	4 GB SIMATIC PC CompactFlash
Ethernet Ports	2x 10/100/1000 Mbps RJ45
USB Ports	3x USB V2.0 (High Current)
Serial Ports	1x (COM1)
Power Supply	24 V DC
Pre-installed Software	Without SIMATIC Software
Product Phase	Phase-Out
Package Dimensions (Calculated)	18.50 x 18.50 x 15.00 cm
Shipping Weight	3.40 kg
Commodity Code	85371098
Export Control Regulations (ECCN)	N

Connections / Interfaces

Interface Type	Details
Ethernet	2x RJ45 (10/100/1000 Mbps)
USB	3x USB V2.0 (High Current)
Serial	1x COM1
Power	24 V DC
Storage	CompactFlash Slot

Installation Guidelines

Power Connection: Connect the unit to a stable 24 V DC power supply. Ensure correct polarity and adequate current capacity for the system.
Mounting: Securely mount the Nanopanel PC in its intended industrial enclosure or panel cutout, ensuring proper ventilation and access for maintenance.
Grounding: Establish a reliable protective earth (PE) connection to minimize electrical interference and ensure operational safety.
Ethernet Connectivity: Connect industrial Ethernet cables to the RJ45 ports for network integration. Use shielded cables in electrically noisy environments.
USB Device Connection: Utilize the USB 2.0 ports for connecting peripheral devices such as keyboards, mice, or external storage.
Serial Communication: Connect serial devices to the COM1 port as required for specific application needs.
Storage Media: The unit comes with a 4 GB CompactFlash card. Ensure it is properly seated in the CompactFlash slot.
Cable Management: Route all cables neatly and securely, separating power and signal cables to prevent interference.
Environmental Considerations: Ensure the installation environment adheres to the specified temperature, humidity, and vibration limits for optimal performance and longevity.

Key Features:

#IPC277D #Nanopanel PC

What is the primary application of the Siemens 6AV7881-3AE00-2BA0?

This Nanopanel PC is primarily designed for industrial automation environments, serving as a Human-Machine Interface (HMI) for process monitoring, control, and data visualization.

What operating system is pre-installed on this device?

The unit runs on Windows Embedded Standard 2009 SP3, providing compatibility with various industrial applications.

Does the 6AV7881-3AE00-2BA0 include SIMATIC software?

No, the device is supplied without pre-installed SIMATIC software, allowing for customization based on specific project requirements.

What are the main connectivity options available?

It features two Gigabit Ethernet RJ45 ports, three high-current USB 2.0 ports, and one serial COM1 interface for flexible integration.

What type of display does the Nanopanel PC feature?

The unit is equipped with a 12-inch touch TFT display for intuitive operation and clear visualization.
