Siemens 6ES7515-2FM00-0AB0 SIMATIC S7-1500F CPU Module

Siemens 6ES7515-2FM00-0AB0 SIMATIC S7-1500F CPU Module

Only 4 item(s) left in stock
  • Manufacturer: Siemens

  • Product No.: 6ES7515-2FM00-0AB0

  • Country of origin:آلمان

  • Product Type: CPU Module

  • Barcode: 85371091

  • Payment: T/T, Western Union

  • Weight: 500g

  • Dimensions: ۷٫۰۰ سانتی‌متر × ۱۲٫۹۰ سانتی‌متر × ۱۴٫۷۰ سانتی‌متر

  • Shipping port: Xiamen

  • Warranty: 12 months

Quantity
View full details

Description

The Siemens 6ES7515-2FM00-0AB0 is a SIMATIC S7-1500F CPU 1515F-2 PN central processing unit, engineered for advanced automation and safety applications within industrial environments. This modular CPU provides a robust work memory of 750 KB for program storage and 3 MB for data, ensuring efficient and reliable processing of complex control tasks.

Equipped with versatile connectivity options, the 6ES7515-2FM00-0AB0 features a first interface with PROFINET IRT and an integrated 2-port switch, alongside a second dedicated Ethernet interface. This configuration facilitates seamless integration into production networks. With a high-speed bit performance of 30 ns, the unit is capable of precise control operations. Operation requires the use of a SIMATIC Memory Card.

Features

  • SIMATIC S7-1500F CPU 1515F-2 PN
  • 750 KB work memory for program
  • 3 MB work memory for data
  • First interface: PROFINET IRT with 2-port switch
  • Second interface: Ethernet
  • 30 ns bit performance
  • Requires SIMATIC Memory Card for operation

Applications

The Siemens 6ES7515-2FM00-0AB0 is suitable for deployment in demanding industrial automation systems requiring high performance and integrated safety functions. Typical applications include:

  • Manufacturing and process control systems
  • Machine automation with integrated safety
  • Complex control tasks requiring high-speed processing
  • Networking within PROFINET IRT and standard Ethernet environments

Ordering Information

Category Detail
Product Phase Phase-Out
Successor Model 6ES7515-2FM01-0AB0

Technical Specifications

Parameter Value
Manufacturer Siemens
Range SIMATIC S7
Subrange S7-1500
Type of Product Central Processing Unit
Model Modular
Supply Voltage 19.2-28.8V DC
Program Memory 750 KB
Data Memory 3 MB
Bit Performance 30 ns
Product Phase Phase-Out
Successor 6ES7515-2FM01-0AB0
Package Dimensions (Calculated) 7.00 cm x 12.90 cm x 14.70 cm
Shipping Weight 0.50 kg
Commodity Code 85371091
Export Control Regulations (ECCN) N
Country of Origin Not specified

Connections / Interfaces

  • Interface 1: PROFINET IRT with integrated 2-port switch
  • Interface 2: Ethernet

Installation Guidelines

  1. De-energize System: Ensure all power to the automation system and associated components is disconnected before beginning installation.
  2. Mounting: Install the CPU module onto the designated SIMATIC S7-1500 rack or mounting rail, ensuring proper mechanical seating and latching.
  3. Power Supply: Connect the 19.2-28.8V DC supply voltage to the appropriate terminals, observing correct polarity.
  4. Memory Card: Insert a compatible SIMATIC Memory Card into the designated slot on the CPU. This card is required for operation.
  5. Network Connections: Connect PROFINET and Ethernet cables to the respective integrated ports. Ensure proper cable routing and strain relief.
  6. Grounding: Verify that the CPU and the entire rack system are properly grounded according to local electrical codes and manufacturer recommendations to ensure operational stability and safety.
  7. Power-Up: Once all connections are secure and verified, re-energize the system. Observe LED indicators for proper initialization.

عملکرد اصلی Siemens 6ES7515-2FM00-0AB0 چیست؟

این یک ماژول CPU ایمن از سری SIMATIC S7-1500F است که برای وظایف اتوماسیون استاندارد و مرتبط با ایمنی طراحی شده و دارای رابط‌های PROFINET IRT و اترنت یکپارچه است.

این CPU از چه نوع حافظه‌ای استفاده می‌کند؟

CPU 1515F-2 PN دارای ۷۵۰ کیلوبایت حافظه برنامه و ۳ مگابایت حافظه داده است. همچنین برای عملکرد به کارت حافظه SIMATIC نیاز دارد.

آیا این CPU از ارتباط PROFINET پشتیبانی می‌کند؟

بله، دارای رابط PROFINET IRT یکپارچه با سوئیچ دو پورته است که امکان ارتباط بلادرنگ در شبکه اتوماسیون را فراهم می‌کند.

منبع تغذیه مورد نیاز این ماژول چیست؟

این ماژول با ولتاژ تغذیه DC بین ۱۹.۲ تا ۲۸.۸ ولت کار می‌کند.

آیا این ماژول برای کاربردهای ایمنی مناسب است؟

بله، به عنوان یک CPU سری «F» (1515F-2 PN)، برای کاربردهای ایمن طراحی شده و عملکردهای ایمنی را مستقیماً در سیستم اتوماسیون استاندارد ادغام می‌کند.
