Siemens SIMATIC IPC 477D 6AV7240-6BD07-6HA2 Panel PC

Only 4 item(s) left in stock

Manufacturer: Siemens
Product No.: 6AV7240-6BD07-6HA2
Country of origin:آلمان
Product Type: Industrial Panel PC
Barcode: 85371098
Payment: T/T, Western Union
Weight: 5g
Dimensions: 43.20 x 27.90 x 12.70 cm
Shipping port: Xiamen
Warranty: 12 months

Description

This is a Siemens SIMATIC IPC 477D, part number 6AV7240-6BD07-6HA2, a robust panel PC designed for industrial automation and control applications. This specific configuration is equipped with an Intel Core i7-3517UE processor, 8 GB of RAM, and an 80 GB MLC Solid-State Drive for reliable performance. It features a 15-inch touch display for operator interaction and comes pre-installed with Windows 7 Ultimate (64-bit). The unit is powered by an AC 110/230V industrial power supply with NAMUR compliance and includes a power cable for European use.

Features

Intel Core i7-3517UE Processor
15-inch resistive touch display
8 GB of system memory
80 GB Standard (MLC) Solid-State Drive (SSD)
Integrated DVD drive
Dual Gigabit Ethernet (IE/PN) ports
Pre-installed with Windows 7 Ultimate (64-bit)
AC 110/230V industrial power supply (NAMUR)

Applications

Human-Machine Interface (HMI) for process visualization
Data acquisition and logging systems
Machine control and automation on the factory floor
Supervisory control and data acquisition (SCADA) nodes

Technical Specifications

Specification	Value
Manufacturer	Siemens
Product Series	SIMATIC IPC 477D
Processor	Intel Core i7-3517UE
Memory	8 GB
Storage	80 GB Standard (MLC) SSD
Display	15-inch Touch Display
Operating System	Windows 7 Ultimate (64-bit)
Optical Drive	DVD
Ethernet Ports	2 x Gigabit Ethernet (10/100/1000 Mbps), IE/PN compatible
USB Ports	4 x Rear, 1 x Front
Serial Port	1 x RS-232
Expansion Slots	Without PCIe
Power Supply	110/230V AC Industrial Power Supply with NAMUR
Product Lifecycle Status	Phase-Out
Country of Origin	Germany (Estimate)
Shipping Weight	5.00 kg
Package Dimensions (Calculated)	43.20 x 27.90 x 12.70 cm

Installation Guidelines

CRITICAL WARNING: Hazardous voltages are present. Installation, wiring, and maintenance must be performed only by qualified personnel. De-energize and lock out all power sources before accessing terminals or making connections to prevent electric shock and equipment damage.

1 Ensure the mounting panel is clean, flat, and prepared with the correct cutout dimensions for the IPC 477D. Verify sufficient clearance for ventilation and cable routing.
2 Insert the Panel PC into the cutout from the front. Secure it evenly from the rear using all provided mounting clamps. Do not overtighten the clamps to avoid deforming the bezel.
3 Connect a dedicated protective earth (PE) or grounding conductor to the designated chassis ground terminal. A low-impedance ground connection is essential for safety and noise immunity.
4 Connect the AC power supply cable to the unit's power input. Ensure the source voltage (110V or 230V AC) matches the power supply rating.
5 Connect Ethernet, USB, and serial communication cables as required. Use shielded cables for all data lines and ensure shields are properly terminated to minimize electrical noise.
6 After verifying all connections are secure and correct, remove the lockout/tagout device and re-energize the main power supply to the panel.

Key Features:

#Industrial Panel PC #SIMATIC IPC 477D

What processor is installed in the 6AV7240-6BD07-6HA2?

This SIMATIC IPC 477D is equipped with an Intel Core i7-3517UE processor.

What operating system comes pre-installed on this Panel PC?

The unit comes with Windows 7 Ultimate, 64-bit edition, pre-installed.

How much memory and storage does this model have?

It is configured with 8 GB of system memory (RAM) and an 80 GB MLC Solid-State Drive (SSD) for storage.

What are the primary network interfaces on this device?

It features two Gigabit Ethernet (10/100/1000 Mbps) ports, which are compatible with Industrial Ethernet (IE) and PROFINET (PN) networks.

What is the power supply requirement for this industrial PC?

This model uses an integrated 110/230V AC industrial power supply unit that is compliant with NAMUR standards.
