Module d'alimentation AC et DC Bently Nevada 114M5330-01 3500/15

Description

The 114M5330-01 is a high-reliability, half-height AC and DC power supply module designed for the Bently Nevada 3500 series machinery protection matrix. This essential power conversion unit installs into designated slots on the left-hand side of a 3500 rack chassis, converting wide-range electrical supply line inputs into the highly regulated, low-noise internal DC distribution rails required by adjacent monitoring and logic processing cards. A single 114M5330-01 module is fully capable of driving an entire, high-density 3500 rack structure alone.

For critical infrastructure demanding maximum asset uptime, the rack configuration allows dual power supply integration. In a redundant pairing system, the lower half-height card functions as the primary supply while the upper module remains in active backup hot-standby mode. If the primary source fails, the backup module immediately assumes the full power load without causing data gaps, signal degradation, or disruption to machine interlock safety networks. This modern hardware variant features improved efficiency over legacy designs and incorporates independent front-panel "SUPPLY OK" indicators for at-a-glance health diagnostics.

Features

• Dual-redundancy architecture permitting hot-swappable module extraction and insertion without disrupting active rack logic.
• Efficient wide-range input distribution filtering to suppress severe field line voltage spikes and EMI surges.
• Dedicated front-panel SUPPLY OK LED indicator providing immediate diagnostic tracking of internal regulation loops.
• Half-height chassis form factor optimized for structural stacking on the left side of the standard 3500 system rack frame.
• Integrated over-voltage and short-circuit clamp protection safeguards delicate downstream instrumentation processors.

Applications

• Supplying highly stabilized, redundant instrumentation power across high-density turbomachinery protection systems.
• Continuous safety loop power infrastructure on large-scale utility steam turbines and critical process compressors.
• High-availability power conditioning inside localized marine, pipeline pumping, and power generation marshalling panels.

Ordering Information

Technical Specifications

Connections/Interfaces

Installation Guidelines

• Chassis Slot Insertion: Slide the half-height module carefully into the designated slots on the far left side of the 3500 rack frame. Firmly seat the card into the rear backplane and hand-tighten the faceplate screws.
• Redundant Slot Mapping: Install the primary power supply bundle into the lower slot position and place the optional redundant backup unit in the upper slot position directly above it.
• Hot-Swap Maintenance: If a dual-supply system is powered, you can remove a faulty power supply or its corresponding rear Power Input Module (PIM) without powering down the rack or interrupting machinery protection.
• ESD Prevention Precautions: Always clip an approved electrostatic discharge wrist strap onto the unpainted rack frame before extracting or handling the circuit boards to shield sensitive components from static discharge.
