CC-TAOX11 | Honeywell | Experion C300 Sortie analogique IOTA (16 canaux)

Product Overview

The CC-TAOX11 is a high-density Analog Output Field Termination Assembly (IOTA) module designed for the Honeywell Experion C300 controller platform. This module serves as the physical interface for 16 independent channels, delivering a standardized 4-20 mA signal to field-side control elements such as valve positioners, variable speed drives, and actuators. Engineered for high-availability process environments, the CC-TAOX11 is widely deployed in oil and gas processing, large-scale power generation, and chemical manufacturing. Its primary function is to convert digital control commands from the C300 processor into precise analog currents, ensuring deterministic control of critical loops while maintaining low signal noise and high thermal stability.

Comprehensive Technical Parameter Matrix

The following table encapsulates the essential electrical and mechanical specifications for the CC-TAOX11 to support engineering design and cabinet layout planning.

Technical Performance & Application FAQ

Does the CC-TAOX11 support redundant configurations?Yes. As a Series C IOTA, the CC-TAOX11 is designed to support redundant I/O module pairs. In a redundant setup, if one Analog Output module fails, the second module maintains the 4-20 mA signal to the field without any bump in the process, ensuring continuous plant operation.

How does the 100 mV peak-to-peak ripple specification affect performance?The low ripple content (< 100 mV p-p) ensures that the control signal is "clean." This is particularly important for sensitive smart positioners or actuators that might misinterpret signal noise as a control command, which could otherwise lead to "hunting" or premature wear of mechanical components.

Is this module suitable for corrosive environments?Yes. The CC-TAOX11 typically features conformal coating as part of the Series C hardware standard. This provides superior protection against humidity, salt spray, and corrosive gases (such as H2S or SO2), making it ideal for offshore platforms and wastewater treatment facilities.

Engineering Deployment & Field Installation Guide

• Termination and Wiring: When connecting field wiring to the 16 channels, ensure that high-quality twisted-pair shielded cable is used. The shield should be grounded at the IOTA end to minimize electromagnetic interference. The compression terminals are designed for ease of use, but ensure that no stray wire strands cause short circuits between adjacent channels.

• Load Impedance Verification: The module is optimized for a 250 Ohm load. Before commissioning, verify the total loop resistance (including the field device and wire resistance). If the impedance is significantly outside the specified range, it may lead to current saturation or drive capability issues.

• Redundancy Linkage: When installing for a redundant application, ensure the redundancy cable is properly seated between the primary and secondary I/O modules. The CC-TAOX11 IOTA provides the physical infrastructure to bridge these signals seamlessly.

Technical Superiority & System Resilience

The Honeywell CC-TAOX11 represents the gold standard in high-density analog control. By consolidating 16 channels into a single Series C footprint, it significantly reduces cabinet space requirements and simplifies field wiring architecture. As an Original and New component, it utilizes advanced diagnostic circuitry that can detect open circuits or shorted field loops, reporting these faults directly to the Experion HMI. This proactive diagnostic capability, combined with the module's robust electrical isolation and low power dissipation, makes the CC-TAOX11 a highly reliable asset for maintaining the peak efficiency of complex industrial control strategies.
