10005/1/1 | Honeywell | Module chien de garde (WD)

Description

Designed for integration into high-integrity safety-instrumented systems (SIS), the Honeywell 10005/1/1 functions as a dedicated hardware watchdog module within the Fail Safe Control (FSC) system architecture. This module continuously supervises processor execution states to maintain predictable, fail-safe operation in the event of a central processing unit (CPU) or system failure. By executing independent hardware diagnostics and monitoring instruction cycles, the 10005/1/1 acts as a critical safety barrier that automatically triggers de-energization or initiates safe-state defaults if processing timing anomalies or hardware faults are detected.

Features

• Provides independent hardware-based watchdog timing for critical safety system loops.
• Continuous monitoring of controller execution states and diagnostic checks.
• Equipped with a dedicated watchdog output (WDGOUT) channel for hardware-level system interlocking.
• Low backplane current draw to optimize overall rack power distribution.
• Standard modular form factor compatible with FSC chassis dimensions.

Applications

• Honeywell FSC (Fail Safe Control) and Safety Manager architectures.
• Emergency Shutdown Systems (ESD) in petrochemical and refinery environments.
• Burner Management Systems (BMS) in power generation and boiler operations.
• Fire and Gas (F&G) detection loops requiring high-integrity hardware interlocking.

Technical Specifications

Installation Guidelines

• De-energize the FSC rack before inserting or extracting the watchdog module to prevent backplane bus transients.
• Align the module printed circuit board carefully with the 3U subrack card guide rails prior to sliding it into the backplane.
• Fully tighten the front panel retaining screws to establish solid mechanical retention and frame grounding.
• Verify that field wiring for the watchdog output (WDGOUT) conforms to proper noise segregation practices, separated from high-voltage AC cables.

Compliance and Certifications

• CE Compliant
• TÜV Certified for Safety-Related Applications
• UL Listed
