Schneider Electric TSXPCX1031 Modicon TSX Micro Connection Cable

Description

Establishing secure serial links in automated environments, the TSXPCX1031 serves as a specialized connection cable designed to interface Modicon TSX Micro controllers and Magelis XBT graphic terminals with DTE (Data Terminal Equipment) modems. With a length of 2.5 meters, this cable provides the physical medium necessary for reliable remote diagnostics, programming, and data acquisition. Engineered to withstand industrial electrical noise, it ensures consistent signal integrity between your control hardware and communication peripherals.

Features

• Enables direct serial communication between Modicon TSX Micro PLCs and DTE modems.
• Generous 2.5-meter length allows for flexible routing within control panels and enclosures.
• Industrial-grade construction designed to resist physical wear and environmental stress.
• Shielded design minimizes electromagnetic interference (EMI) during data transmission.

Applications

• Remote monitoring and telemetry systems utilizing DTE modems.
• SCADA and HMI integration with Modicon TSX Micro automation platforms.
• Industrial serial communication networks and diagnostic setups.

Technical Specifications

Installation Guidelines

• Routing: Route the communication cable away from high-voltage AC power lines and variable frequency drive (VFD) cables to prevent electromagnetic coupling.
• Bend Radius: Maintain the recommended minimum bend radius during installation to avoid damaging the internal conductors and shielding.
• Connection: Ensure all connector thumbscrews or latches are fully secured to prevent intermittent connection loss due to vibration.
