ABB PP845A 3BSE042235R2 Panel 800 Operator HMI

Hanya 4 item tersisa di stok

Produsen: ABB
Nomor Produk: PP845A 3BSE042235R2
Negara asal:Swiss
Jenis Produk: Touch Screen
Kode batang: 8537101190
Pembayaran: T/T, Western Union
Berat: 2000g
Dimensi: 302 x 228 x 60 mm
Pelabuhan pengiriman: Xiamen
Garansi: 12 bulan

Description

The PP845A 3BSE042235R2 is a space-saving human-machine interface device configured to deliver real-time process monitoring and machine-level control across industrial automation systems. Operating as a high-performance Panel 800 Operator HMI, this terminal features an integrated color liquid crystal touch display designed for displaying graphical objects, structural plant text, and dynamic system variables. The underlying hardware platform utilizes updated processor and power electronics to interpret operator inputs and manage fieldbus interactions. Engineered specifically for seamless operation inside the ABB Control Network and alongside AC 800M controllers, the PP845A 3BSE042235R2 supports integrated controller-level alarm handling and remains compatible with multiple third-party PLCs through an embedded driver library.

Features

Utilizes an object-oriented development framework to structure text displaying, recipe deployment, and historical alarm actions
Features a slim powder-coated aluminum structural casing engineered to reduce overall enclosure panel insertion depth
Equipped with front-enclosure protection configurations to survive harsh process deployment states
Configured using the dedicated Panel Builder software application to transfer and download localized project databases

Applications

Human-machine interface terminal for AC 800M process control clusters
Multi-brand PLC diagnostic displaying and equipment maneuvering stations

Technical Specifications

Parameter	Value
Manufacturer	ABB
Model Designation	PP845A
Product ID	3BSE042235R2
Display Type	10.4 inch TFT Color Touch Display
Resolution	800x640 pixels
Content Support	Graphics & Text
Hardware Variant	New CPU and power boards
Configuration Software	Requires Panel Builder 800 version 5
Enclosure Rating	IP66 (front enclosure)
Front Panel Dimensions (W x H x D)	302 x 228 x 60 mm
Cut-out Dimensions	265 x 206 mm
Mounting Depth	58 mm
Weight	2 kg

Installation Guidelines

Cut-out Preparation: Prepare a clear rectangular panel opening checking that cut-out dimensions match the exact 265 x 206 mm layout tracking.
Touch Protection: To preserve the structural reliability of the interactive screen face, it is recommended to fit the dedicated accessory RX845 Touch Cover over the front interface.
Enclosure Sealing: Mount the unit firmly using the provided structural bracket fasteners to squeeze front seals against the plate, ensuring an airtight IP66 seal boundary.

Compliance and Certifications

DNV
UL
Note: This specific CPU/power board hardware configuration does not carry a UL 1604 certification.

Key Features:

#HMI Terminals #Panel 800

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Which software utility is mandatory for loading operational projects into this unit?

This operator terminal requires Panel Builder 800 version 5 to execute project configuration tasks and transfer data to the module.

What protection classification is specified for the front surface of the device?

The front enclosure frame is built to withstand rigorous industrial environment cleanings in accordance with the IP66 rating standard.

Does this particular hardware iteration carry the UL 1604 certification?

No, because of updated CPU and power supply electronic board components, this specific hardware revision does not feature a UL 1604 certification.
