Bently Nevada 330101-00-19-10-02-CN 3300 XL 8 mm Proximity Probe

Hanya 7 item tersisa di stok

Produsen: Bently Nevada
Nomor Produk: 330101-00-19-10-02-CN
Negara asal:Amerika Serikat
Jenis Produk: Proximity Probes
Pembayaran: T/T, Western Union
Berat: 323g
Pelabuhan pengiriman: Xiamen
Garansi: 12 bulan

Lihat detail lengkap

Description

Designed for high-precision machinery vibration and position monitoring, the Bently Nevada 330101-00-19-10-02-CN non-contacting proximity probe serves as a critical sensor component in 3300 XL 8 mm transducer systems. This eddy current sensor provides stable, accurate dynamic and static measurements of shaft displacement, vibration, and speed in high-speed rotating machinery. The physical construction incorporates a durable polyphenylene sulfide (PPS) tip and a corrosion-resistant stainless steel case, facilitating dependable operation in aggressive industrial environments.

The 330101-00-19-10-02-CN is configured with a 3/8-24 UNF thread, 0 inches of unthreaded length, and a 1.9-inch overall case length. Featuring a 1.0-meter standard coaxial cable terminated with a ClickLoc connector, it ensures secure signal transmission back to the proximitor sensor module. This variant is specifically certified under CN agency approvals for specialized regional compliance.

Features

Highly reliable non-contact eddy current measurement technology.
Robust polyphenylene sulfide (PPS) probe tip for moisture and chemical resistance.
Corrosion-resistant AISI 303 or 304 stainless steel housing.
Secure ClickLoc miniature coaxial connector preventing accidental disconnects.
Fully compatible with Bently Nevada 3300 XL series proximitors and extension cables.

Applications

Steam and gas turbine shaft vibration and axial position monitoring.
Centrifugal and axial compressor health monitoring.
High-speed electric motor and generator bearing diagnostics.
Industrial gearbox shaft displacement and speed detection.
Petrochemical and power generation plant machinery protection systems.

Ordering Information

Option Code	Specification Type	Selected Option Value
330101	Base Model / Thread	3300 XL 8 mm Probe, 3/8-24 UNF thread, without armor
00	Unthreaded Length	0 in
19	Overall Case Length	1.9 in
10	Total Length	1.0 meter (3.3 feet)
02	Connector and Cable Type	Miniature coaxial ClickLoc connector, standard cable
CN	Agency Approval	Country-specific approvals (CN Option)

Technical Specifications

Parameter	Value / Range
Manufacturer	Bently Nevada
Part Number / Model	330101-00-19-10-02-CN
Series	3300 XL 8 mm	Country of Origin	USA
Probe Tip Material	Polyphenylene sulfide (PPS)
Probe Case Material	AISI 303 or 304 stainless steel (SST)
Thread Size	3/8-24 UNF
Unthreaded Length	0 in
Overall Case Length	1.9 in
Total Cable Length	1.0 meter (3.3 feet)
Connector Type	Miniature coaxial ClickLoc
Operating and Storage Temperature	-51 degC to +177 degC (-60 degF to +351 degF)
Weight	0.323 kg

Installation Guidelines

Ensure proper physical clearance around the probe tip to prevent side-loading interference from surrounding metals.
Observe minimum bend radius limits for the coaxial cable during routing to avoid signal attenuation or physical damage.
Tighten the probe case thread to the specified torque settings to prevent loosening without damaging the threaded housing.
Use connector protectors or terminal junction boxes to protect critical connections from moisture and dust intrusion.

Model Number / Title	Condition	Availability	Action
Bently Nevada 330901-00-78-10-02-00 3300 XL Probe Proksimitas NSv	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-11-01 3300 XL Probe Proksimitas 8 mm	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-02-01 3300 XL Probe Proksimitas 8 mm	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 XL #Proximity Probes

What is the physical configuration of the 330101-00-19-10-02-CN proximity probe?

The probe features a 3/8-24 UNF thread, 0 inches of unthreaded length, a 1.9-inch overall case length, a 1.0-meter (3.3 feet) total cable length, standard miniature coaxial ClickLoc connector, and CN country-specific approvals.

What material is used for the probe tip and casing?

The probe tip is made from polyphenylene sulfide (PPS), and the casing is constructed from AISI 303 or 304 stainless steel (SST) for superior industrial durability.

What does the CN option signify?

The CN option designates country-specific regulatory approvals, often covering Chinese industrial safety and hazardous location standard compliance.

What are the operational temperature limits for this sensor?

The operating and storage temperature range for this proximity probe is -51 degC to +177 degC (-60 degF to +351 degF).
