Mitsubishi Electric GT2708-VTBA GOT2000 Series Graphic Operation Terminal HMI

Hanya 10 item tersisa di stok

Produsen: Mitsubishi Electric
Nomor Produk: GT2708-VTBA
Negara asal:Amerika Serikat
Jenis Produk: Graphic Operation Terminals
Pembayaran: T/T, Western Union
Berat: 1500g
Dimensi: 24.1 cm x 19.4 cm x 5.2 cm
Pelabuhan pengiriman: Xiamen
Garansi: 12 bulan

Lihat detail lengkap

Description

Designed for high-performance visualization in demanding industrial environments, the GT2708-VTBA functions as a premium human-machine interface (HMI) within the Mitsubishi Electric GOT2000 Series. Featuring an 8.4-inch TFT color display with VGA resolution, this terminal delivers clear, high-contrast graphics and responsive operation. The rugged design incorporates a black frame bezel, making it suitable for standard control panel installations across diverse automation sectors.

This terminal is engineered to operate reliably under variable conditions, supporting both horizontal and vertical mounting configurations. With an integrated self-cooling mechanism, the unit eliminates the need for maintenance-prone cooling fans, ensuring uninterrupted operation. It runs on a wide AC power supply range (100 to 240 VAC), providing the electrical stability needed for complex factory automation architectures and industrial machinery control.

Features

Vibrant Display: 8.4-inch TFT color screen with VGA (640 x 480 pixels) resolution for precise graphical representation.
Flexible Mounting: Fully operational in both horizontal and vertical orientations to maximize panel space efficiency.
Robust Power Handling: Wide AC input range (100 to 240 VAC) with a permissible instantaneous power failure time of up to 20ms.
Fanless Design: Integrated self-cooling architecture prevents dust ingress and increases physical reliability.
Excellent Noise Immunity: High resistance to electrical noise (1500Vp-p noise voltage, 1us width).

Applications

Automotive assembly lines and robot control stations
Water and wastewater treatment monitoring
Packaging, sorting, and material handling systems
Food and beverage processing machinery
General manufacturing and control cabinet integration

Technical Specifications

Manufacturer	Mitsubishi Electric
Model/Part Number	GT2708-VTBA
Series	GOT2000 Series (GT27)
Screen Size	8.4 inches
Display Type	TFT Color
Resolution	VGA (640 x 480 pixels)
Frame Color	Black
Input Voltage	100 to 240 VAC (+10%, -15%)
Power Consumption (Max)	41 W or less
Power Consumption (Stand-alone)	15 W (10 W with backlight off)
Inrush Current	60 A or less (2ms, ambient 25 degC)
Operating Temperature	0 to 55 degC (horizontal), 0 to 50 degC (vertical)
Storage Temperature	-20 to 60 degC
Humidity Range	10% to 90% RH (non-condensing)
Operating Altitude	2000m or less
Vibration/Impact Resistance	Compliant with JIS B 3502 and IEC 61131-2 (147 m/s2 / 15G)
Insulation Resistance	10 Mohm or higher (500 VDC between terminal and ground)
Withstand Voltage	1500 VAC for 1 minute
Dimensions (W x H x D)	24.1 cm x 19.4 cm x 5.2 cm
Weight	1.5 Kg (excluding brackets)

Connections and Interfaces

Connection Type	Specification / Terminal Standard
Terminal Block	Clamp terminals for M3 screw (RAV1.25-3, V2-S3.3, V2-N3A, FV2-N3A)
Tightening Torque	0.5 to 0.8 N.m
Applicable Wire Size	0.75 to 2 mm2

Installation Guidelines

Ensure the installation location is inside a secure control panel protected from greasy fumes, corrosive or flammable gases, and conductive dust.
Keep clear spacing around the unit to facilitate self-cooling and maintain internal enclosure temperatures within the specified 0 to 55 degC operating range.
Verify the installation orientation; limit maximum operating temperature to 50 degC if mounting vertically.
Ensure the terminal is properly grounded using the ground terminal with a resistance of 100 Ohms or less.

Key Features:

#GOT2000 Series #Graphic Operation Terminals

What is the screen resolution and size of the GT2708-VTBA?

The GT2708-VTBA features an 8.4-inch TFT color display with a VGA resolution of 640 x 480 pixels.

What are the mounting orientation and temperature limits for this HMI?

The terminal supports both horizontal and vertical installation. The operating ambient temperature limit is 0 to 55 degC for horizontal mounting and 0 to 50 degC for vertical mounting.

What type of power supply does the GT2708-VTBA require?

It requires an input power supply voltage of 100 to 240 VAC (+10%, -15%) at 50/60 Hz.
