Siemens 6ES7151-1AA02-0AB0 SIMATIC DP ET 200S Interface Module

Hanya 8 item tersisa di stok

Produsen: Siemens
Nomor Produk: 6ES7151-1AA02-0AB0
Negara asal:Jerman
Jenis Produk: Interface Module
Kode batang: 8537101190
Pembayaran: T/T, Western Union
Berat: 200g
Dimensi: 12.7 x 12.7 x 7.6 cm
Pelabuhan pengiriman: Xiamen
Garansi: 12 bulan

Description

The Siemens 6ES7151-1AA02-0AB0 Simatic DP Interface Module IM151-1 is a standard interface module designed for the SIMATIC DP ET 200S distributed I/O system. It facilitates communication between decentralized I/O modules and a central controller via the PROFIBUS DP network. This module supports a transmission rate of up to 12 Mbit/s, ensuring reliable data exchange for real-time industrial automation processes.

With a capacity to handle up to 128 bytes of data for both input and output, the Siemens 6ES7151-1AA02-0AB0 IM151-1 offers sufficient capability for complex signal processing and control tasks. Its architecture allows for the connection of up to 63 modules, including power modules, electronic modules, and motor starter modules, providing a flexible and scalable solution. Installation is streamlined through its 9-way Sub-D connector and an included terminating module, which helps maintain proper bus communication and network integrity. The compact design of the 6ES7151-1AA02-0AB0 module makes it suitable for integration into both new and existing industrial setups.

Features

Standard interface module for SIMATIC DP ET 200S distributed I/O systems
Supports PROFIBUS DP communication up to 12 Mbit/s
Handles up to 128 bytes of input data
Handles up to 128 bytes of output data
Allows connection of up to 63 modules (power, electronic, motor starter)
Equipped with a 9-way Sub-D connector
Includes a terminating module for bus integrity

Applications

Distributed I/O systems in industrial automation
Manufacturing process control
General process automation environments
Machinery control systems

Technical Specifications

Parameter	Value
Manufacturer	Siemens
Model Number	6ES7151-1AA02-0AB0
Module Type	Interface Module
Product Series	SIMATIC DP ET 200S
Communication Protocol	PROFIBUS DP
Communication Service	Ethernet router
Transmission Rate	Up to 12 Mbit/s
Input Data Capacity	Up to 128 bytes
Output Data Capacity	Up to 128 bytes
Max. Connectable Modules	63
Connector Type	9-way Sub-D
System	PLC
Condition	Brand New
Discontinued Status	Active
Shipping Weight	0.2 kg
Package Dimensions (Calculated)	12.7 x 12.7 x 7.6 cm
Country of Origin	Germany
HS Code	8537101190
Minimum Order Quantity (MOQ)	1

Installation Guidelines

Ensure that the power to the SIMATIC DP ET 200S system and associated components is de-energized before beginning installation.
Mount the 6ES7151-1AA02-0AB0 interface module within the designated slot in the SIMATIC DP ET 200S distributed I/O rack.
Connect the PROFIBUS DP network cable to the 9-way Sub-D connector on the module.
If this module is at the end of a PROFIBUS DP segment, install the included terminating module to ensure proper bus communication and network integrity.
Verify all physical connections are secure and correctly seated.
Re-energize the system and perform functional tests to confirm proper communication and operation.

Key Features:

#Interface Module #SIMATIC DP ET 200S

What is the primary communication protocol supported by this module?

The Siemens 6ES7151-1AA02-0AB0 module primarily supports PROFIBUS DP for communication within the ET 200S distributed I/O system.

What is the maximum data capacity for inputs and outputs?

This interface module can handle up to 128 bytes of data for both input and output signals.

How many modules can be connected to the IM151-1 interface?

The module's architecture allows for the connection of up to 63 modules, including power, electronic, and motor starter modules.

What type of connector is used for the PROFIBUS DP connection?

The module utilizes a 9-way Sub-D connector for its PROFIBUS DP network connection.

Is a terminating module required for installation?

Yes, an included terminating module should be installed if this module is at the end of a PROFIBUS DP segment to ensure proper bus communication.
