The 131F1238 (131F1238) is a high-performance VLT HVAC Drive designed specifically for industrial climate control systems. Engineered by Danfoss, this frequency converter provides optimized motor control for fans, pumps, and compressors in demanding environments such as power plants, chemical processing facilities, and large-scale manufacturing hubs. With a power rating of 3.0 kW (4.0 HP), the 131F1238 focuses on reducing energy consumption and mechanical wear through precise speed regulation. Its integration into building management systems (BMS) ensures maximum uptime and system stability, delivering the high reliability required for critical infrastructure automation.
The model code FC-102P3K0T4E20 follows a specific functional logic:
FC: Identifies the VLT product group.
102: Specifies the HVAC-optimized drive series.
P3K0: Represents the power rating of 3.0 kW (4.0 HP).
T: Indicates compatibility with three-phase power systems.
4: Denotes a mains voltage range of 380 - 480 VAC.
E20: Signifies an IP20 enclosure rating, suitable for installation within protected control cabinets or cleanroom environments.
| Attribute | Specification |
| Model | 131F1238 |
| Brand | Danfoss |
| Power Rating | 3.0 kW (4.0 HP) |
| Input Voltage | 380 - 480 VAC (Three Phase) |
| Enclosure Rating | IP20 |
| Product Group | VLT HVAC Drive FC 102 |
| Operating Temp | -10 to 45 deg C (at full load) |
| Cooling | Forced Air Cooling |
| Net Weight | 4.9 kg |
| Shipping Weight | 8.0 kg |
Can the 131F1238 be used in high-vibration industrial environments?
While the IP20 rating is designed for cabinet mounting, the VLT series is tested for industrial-grade vibration resistance. However, for extreme vibration, ensure the control cabinet utilizes proper shock absorption mounts to prevent mechanical stress on the internal PCB components.
How does this drive handle harmonic distortion in power plant grids?
The FC 102 series includes integrated DC link reactors as standard. This significantly reduces harmonic interference on the mains supply, meeting stringent EMC requirements without the need for additional external filters in most applications.
What is the procedure if the drive displays an Overvoltage Trip?
Check the mains voltage for surges or investigate if the motor is being driven by the load (regenerative energy). If the ramp-down time is too short for the inertia of the fan or pump, increase the deceleration time in the drive settings to stabilize the DC link voltage.
Heat Dissipation Management: Given the IP20 rating, this drive must be installed in a ventilated enclosure. Maintain a minimum clearance of 100 mm above and below the unit to allow for unrestricted airflow from the internal cooling fans. If multiple units are mounted side-by-side, ensure the cabinet's total heat load does not cause the ambient temperature to exceed 45 deg C.
EMC Correct Installation: To minimize electromagnetic interference, use shielded motor cables and ensure the shield has a 360-degree contact with the metal decoupling plate. Keep control wiring and high-power motor cables separated by at least 200 mm to prevent signal noise in the analog I/O loops.
Grounding Protocol: Ensure the drive is connected to a low-impedance ground. The PE (Protective Earth) connection must be established before applying power. For industrial automation systems with high-frequency noise, a flat braided copper strap is recommended for the ground connection to provide better performance than a standard round wire.
Global Express Shipping
Returns & Warranty
Manufacturer: Danfoss
Product No.: 131F1238
Country of origin:Denmark
Product Type: FC-102P3K0T4E20
Payment: T/T, Western Union
Weight: 8000g
Shipping port: Xiamen
Warranty: 12 months
