ABB 3HAC059122-001 DSQC3026 Serial Measurement Board

SKU 3HAC059122-001 DSQC3026

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: 3HAC059122-001 DSQC3026
Origin Indonesia
Product Type: Serial Measurement Board
Barcode: 85044090
Payment: T/T, Western Union
Weight: 0.04 kg
Dimensions: 100 x 60 x 15 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The ABB 3HAC059122-001 DSQC3026 is a Serial Measurement Board used in ABB robotic systems for axis measurement and feedback handling.

ABB identifies the exact Product ID as 3HAC059122-001 and the catalog description as SMB DSQC3026. The board is used as a robot spare part and provides the measurement interface between robot-axis feedback devices and the robot control system.

ABB robot electrical documentation identifies DSQC3026 SMB as the Serial Measurement Board and shows dedicated measurement connections for robot axes, excitation signals, and the battery pack.

The compact board measures 100 x 60 x 15 mm and weighs 0.04 kg. ABB lists Indonesia as the country of origin.

Features

ABB robot Serial Measurement Board
Product ID 3HAC059122-001
DSQC3026 hardware designation
Axis measurement and feedback interface
Interfaces with multiple robot-axis measurement channels
Excitation signal connections for axis feedback circuits
Battery-backed measurement architecture
Compact robot-mounted electronic board
ABB robotics spare-part hardware
New part classification in ABB product data

Applications

Robot axis position measurement
Motor feedback signal processing
Robot arm measurement systems
Serial measurement architecture in ABB robots
Maintenance of ABB robotic axis feedback systems
Replacement of installed DSQC3026 SMB boards

Technical Specifications

Parameter	Specification
Manufacturer	ABB
Product ID	3HAC059122-001
Hardware Designation	DSQC3026
Catalog Description	SMB DSQC3026
Product Type	Serial Measurement Board
Application	ABB Robotics
Country of Origin	Indonesia
Part Type	New
Product Net Weight	0.04 kg
Gross Weight	0.04 kg
Product Length	100 mm
Product Width	60 mm
Product Height	15 mm
Customs Tariff Number	85044090
Minimum Order Quantity	1 piece
Selling Unit	Piece

ABB's product record gives the exact identity, origin, weight, dimensions, customs classification, and new-part status for 3HAC059122-001.

Measurement Interface

ABB electrical documentation for DSQC3026 shows axis-measurement connections for multiple robot axes.

The SMB interface includes signal paths identified for:

X-axis measurement signals
Y-axis measurement signals
Excitation signals
Measurement signal returns
Battery pack connection
Serial measurement interface

The ABB circuit documentation specifically labels DSQC3026 as the Serial Measurement Board.

System Role

The DSQC3026 forms part of the robot's axis feedback architecture.

Resolver or measurement signals from robot axes are routed through the SMB. The board allows the robot controller to maintain position information required for coordinated axis operation.

Because SMB hardware is directly involved in robot position feedback, replacement should preserve the exact Product ID and DSQC hardware designation.

Installation Guidelines

Verify the complete 3HAC059122-001 Product ID before replacement.
Confirm the installed board is marked DSQC3026.
Record all SMB and axis-feedback connections before removal.
Back up robot calibration and configuration data before replacing measurement hardware.
Isolate robot power before disconnecting the SMB.
Observe ESD precautions when handling the board.
Inspect feedback connectors and wiring before installing the replacement.
Verify axis position and robot calibration status after installation.

Replacement Notes

Match both 3HAC059122-001 and DSQC3026 when sourcing a replacement.
Do not select another ABB SMB board only by physical dimensions.
Preserve robot-axis calibration and measurement data before replacement.
Confirm the installed robot hardware configuration before commissioning the new board.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the ABB 3HAC059122-001 DSQC3026?

The ABB 3HAC059122-001 DSQC3026 is a Serial Measurement Board used in ABB robotic systems for robot-axis measurement and feedback handling.

What function does the ABB DSQC3026 perform?

The ABB 3HAC059122-001 DSQC3026 interfaces with robot-axis measurement circuits and provides the serial measurement hardware used for position-feedback processing.

Does the DSQC3026 connect to multiple robot axes?

The ABB 3HAC059122-001 DSQC3026 is shown in ABB electrical documentation with measurement connections for multiple robot axes, excitation signals, and associated feedback circuits.

What should be backed up before replacing a DSQC3026 SMB?

The ABB 3HAC059122-001 DSQC3026 replacement should be preceded by a backup of robot configuration and calibration data because the SMB participates in axis measurement and position-feedback functions.

What are the dimensions of the ABB 3HAC059122-001?

The ABB 3HAC059122-001 DSQC3026 measures 100 x 60 x 15 mm and has a listed net weight of 0.04 kg.

What should be checked when sourcing a DSQC3026 replacement?

The ABB 3HAC059122-001 DSQC3026 replacement should match the exact Product ID, DSQC designation, robot hardware configuration, feedback connections, and installed measurement architecture.
