The ABB FS300R12KE3 / AGDR-62C (Product ID: 64717812) is a high-power IGBT module and gate driver assembly designed for ABB industrial frequency converters and variable speed drive systems.
This assembly combines the Infineon TRENCHSTOP™ FS300R12KE3 IGBT with the ABB AGDR-62C gate driver board, providing optimized switching performance, reduced parasitic inductance, and stable operation in industrial inverter systems.
The AGDR-62C gate driver manages gate control and protection functions including desaturation detection, overcurrent protection, and thermal monitoring. It is commonly applied in ABB ACS600 / ACS800 drives, wind power systems, and industrial UPS platforms.
Matched IGBT module + gate driver board assembly
FS300R12KE3 1200V IGBT module
AGDR-62C high-speed gate driver
Compatible with ABB ACS600 / ACS800 drive systems
Integrated desaturation short-circuit protection
Low-inductance gate connection design
Switching frequency up to 10 kHz
Designed for industrial power conversion systems
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | FS300R12KE3 / AGDR-62C |
| Product ID | 64717812 |
| Type | IGBT Module + Gate Driver Assembly |
| IGBT Technology | Infineon TRENCHSTOP™ IGBT3 |
| Voltage Rating | 1200 V DC |
| Collector Current | 300 A |
| DC Bus Voltage | 400–480 V DC |
| Switching Frequency | Up to 10 kHz |
| Driver Board | AGDR-62C |
| Cooling Method | Forced air / liquid cooling + TIM |
| Insulation Voltage | 2500 V AC |
| Mounting | Screw-mounted power module |
| Weight | 0.40 kg |
| Dimensions | 20 × 198 × 262 mm |
| Origin | Switzerland / Germany |
| HS Code | 8537101190 |
The FS300R12KE3 IGBT module performs high-power switching in inverter stages, while the AGDR-62C gate driver board provides precise gate signal control and protection logic.
The driver connects directly to the IGBT terminals using a low-inductance interface, reducing switching losses and improving dynamic response in high-power drive applications.
Built-in protection includes:
Desaturation detection
Gate voltage monitoring
Soft turn-off under fault conditions
Thermal protection logic
Proper thermal interface design is required for reliable IGBT operation.
Clean heatsink surfaces before installation and apply uniform thermal interface material (TIM).
Recommended torque values:
Initial torque: 2.0 Nm
Final torque: 3.0–6.0 Nm
Cooling may be air-cooled or liquid-cooled depending on system power density.
The AGDR-62C gate driver board contains sensitive electronics including CMOS and optical isolation components.
Handling rules:
Use grounded ESD protection
Avoid direct PCB contact
Ensure DC bus stability before activation
Do not energize gate supply in unstable system states
The ABB FS300R12KE3 / AGDR-62C is used in:
ABB ACS600 / ACS800 industrial drives
Motor control systems
Wind turbine converters
Industrial UPS systems
High-power frequency converters
Heavy-duty automation systems
Product ID: 64717812
Type: FS300R12KE3 / AGDR-62C
Kit: IGBT module + gate driver board + connectors
HS Code: 8537101190
What systems use this assembly?
It is used in ABB ACS600 / ACS800 drives, wind power systems, and industrial converters.
Why is it sold as a kit?
Because the IGBT switching characteristics and gate driver parameters must be matched precisely.
What causes driver faults?
Typical causes include short-circuit events, desaturation faults, communication loss, or low gate supply voltage.
