ABB ICSC08L1 FPR3319101R1082 CS31 Binary Input/Output Unit

SKU ICSC08L1 FPR3319101R1082

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: ICSC08L1 FPR3319101R1082
Origin Germany
Product Type: Binary Input Output Modules
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.45 kg
Dimensions: 115 mm x 120 mm x 60 mm (D x W x H)
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

Description

The ABB ICSC08L1, carrying the order code FPR3319101R1082 (also referenced under variants FPR3329101R1082, FPR3329101R0086, and FPR3329101R0084), is a professional-grade binary input/output unit developed for the Advant Controller 31 (AC 31) automation system. Operating as a versatile remote unit on the CS31 system bus, the device features 8 independent channels that can be user-programmed or configured via control logic. Each channel is dynamically capable of functioning either as a 24 V d.c. binary input or a 24 V d.c., 0.5 A transistor output.

Designed for long-term reliability and straightforward migration, this module can interface with newer system topologies such as the ICMK-CS31 remote interface combined with an XC08L1 binary extension module. This deployment preserves the functional integrity and software behavior of legacy 30 series applications without necessitating comprehensive user program rewrites.

Ordering Information

Part Number / Model	Order Code (Product ID)	Description
ICSC08L1	FPR3319101R1082	CS31 Binary Input/Output Unit, 8 Channels, 24 V d.c.
ICSC08L1	FPR3329101R1082	CS31 Binary Input/Output Unit (Alternative Order Code Variant)
ICSC08L1	FPR3329101R0086	CS31 Binary Input/Output Unit (Alternative Order Code Variant)
ICSC08L1	FPR3329101R0084	CS31 Binary Input/Output Unit (Alternative Order Code Variant)
ICMK-CS31	Legacy Dependent	Remote Interface Module (Recommended Migration Path)
XC08L1	Legacy Dependent	Binary Extension Module (Recommended Migration Path)

Features

Provides 8 flexible, non-isolated binary channels configuration-dependent for input or output use.
Supports dual-purpose electrical signaling as a 24 V d.c. digital input or a 24 V d.c. 0.5 A transistor output.
Fully compatible with standard CS31 system bus infrastructure utilizing RS 485 serial communication protocols.
Serves as an orderable legacy asset, with alternative modern system mapping solutions utilizing ICMK-CS31 and XC08L1 platforms.
Designed to interface seamlessly with multi-voltage network environments supporting 24 V d.c., 120 V a.c., and 230 V a.c. power bases.

Applications

Distributed digital I/O expansion across legacy Advant Controller 31 (AC 31) processor systems.
Industrial factory automation demanding centralized field device monitoring and discrete low-current transistor switching.
Modernization projects migrating legacy 30 series fieldbus modules onto standardized hardware layers.

Technical Specifications

Parameter	Specification
Manufacturer	ABB
Model	ICSC08L1
Module Type	Binary Input/Output Unit
Number of Channels	8 channels
Input Ratings	24 V d.c.
Output Ratings	24 V d.c., 0.5 A transistor
Nominal System Voltages	24 V d.c., 120 V a.c., 230 V a.c.
Fieldbus Interface	CS31 System Bus (RS 485)

Installation Guidelines

Base Mounting: Install the remote unit onto the matching ECZ plug-in base assembly. Ensure locking clips are securely fastened.
Fieldbus Termination: Connect the shielded twisted-pair communication bus to the designated RS 485 fieldbus terminals. Apply a 120 ohm, 0.25 W termination resistor across fieldbus extremities if the module resides at the physical line ends.
Addressing: Set the decimal network station address manually by manipulating the physical hardware dip-switches located on the ECZ plug-in base prior to powering up the system.
Wiring Requirements: Route signal wires separate from heavy power mains to minimize electro-magnetic interference. Strip field connections neatly and adhere to terminal torque limits to prevent contact degradation.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the function of each channel on the device?

Each of the 8 channels can be individually utilized as a 24 V d.c. binary input or configured to operate as a 24 V d.c. 0.5 A transistor output.

Which fieldbus communication protocol does the unit use?

The unit communicates over the RS 485 serial fieldbus using the proprietary CS31 protocol.

How is the system station address assigned to this module?

The node address is established by physically adjusting the binary-weighted dip-switches located on the structural ECZ plug-in base.
