Allen-Bradley 1756-L62 ControlLogix 4 MB Memory Controller

SKU 1756-L62

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Allen-Bradley
  • Product No.: 1756-L62
  • Origin United States
  • Product Type: ControlLogix Logix5562 Processor
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.35 kg
  • Dimensions: 145 mm x 35 mm x 120 mm (W x H x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

ControlLogix PLC Controllers

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Allen-Bradley 1756-L62 ControlLogix 4 MB Memory Controller

Download Open in new tab
Quantità
Call sales Contact

Product Description

Allen-Bradley 1756-L62 is a ControlLogix 5560 controller that provides 4 MB of user memory for industrial control and automation applications. The unit processes control tasks, manages system I/O, and supports multi-controller configurations within a standard 1756 chassis. It features an integrated RS-232 serial communication port and utilizes a removable lithium battery module for memory retention and clock support during power-down conditions. Nonvolatile memory storage is expanded via an optional CompactFlash card.

Features

  • Built-in RS-232 serial port for programming and serial communication protocols
  • 4 MB user memory capacity for program logic and data storage
  • Supports up to 250 controller connections
  • Nonvolatile memory backup via optional CompactFlash card
  • Removable lithium battery options (1756-BA1 or 1756-BA2) for memory retention during power interruptions
  • Front panel status indicators for diagnostic and operational monitoring
  • Three-position mode switch (RUN, REM, PROG) for system operational control

Applications

  • Industrial process automation and batch control systems
  • Machine control and discrete manufacturing lines
  • Distributed I/O and multi-chassis control configurations
  • Motion control and axis integration

Technical Specifications

Parameter Specification
Manufacturer Allen-Bradley / Rockwell Automation
Product Family ControlLogix 5560
Catalog Number 1756-L62
User Memory 4 MB
Built-in Ports RS-232 serial port
Controller Connections 250
Nonvolatile Memory CompactFlash card (optional, e.g., 1784-CF128)
Memory Retention / Clock Backup Lithium battery (1756-BA1 for Series A; 1756-BA2 for Series B)
Operating Modes RUN, REM (Remote), PROG (Program)
Status Display 6 LED indicators (RUN, I/O, FORCE, RS-232, BAT, OK)

Connections/Interfaces

Interface Function
RS-232 Port Serial communication interface for DF1, DH-485, ASCII, or programming connections via 1756-CP3 or 1747-CP3 cable
CompactFlash Slot Connector interface for nonvolatile memory card installation
Battery Connector Dedicated terminal connection for 1756-BA1 or 1756-BA2 battery assembly
Backplane Connector Multi-pin chassis connector for power, data, and system bus communication

Installation Guidelines

  • Chassis Mounting: The module can be installed in any available slot of a standard ControlLogix 1756 chassis.
  • Electrostatic Discharge: Handle the device using an approved grounding wriststrap and static-safe workstation to avoid component damage.
  • Battery Maintenance: Verify battery polarity when connecting the 1756-BA1 or 1756-BA2 battery. Replace batteries according to ambient operating temperature schedules to prevent memory loss.
  • Serial Cable Routing: Ensure the serial cable length does not exceed 15.2 m (50 ft) when constructing custom serial interfaces.
  • CompactFlash Handling: Insert or remove the CompactFlash card only when power is disconnected or the area is known to be nonhazardous to prevent electrical arcing.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What battery is used for memory retention in the controller?
Series A controllers use the 1756-BA1 battery or 1756-BATM module, while Series B controllers use the 1756-BA2 lithium battery.
How is nonvolatile memory supported on the device?
Nonvolatile memory storage and program backup are supported using an optional CompactFlash card, such as the 1784-CF128.
What serial communication protocols are supported on the built-in port?
The RS-232 serial port supports protocols such as DF1 Master/Slave, DF1 Point-to-Point, DF1 Radio Modem, DH-485, and ASCII.
How many controller connections can the unit maintain?
The device supports up to 250 controller connections.
