Allen-Bradley VPL-B1001M-CK12AA Kinetix VP Low-Inertia Servo Motor

SKU VPL-B1001M-CK12AA

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Allen-Bradley
  • Product No.: VPL-B1001M-CK12AA
  • Origin United States
  • Product Type: Servo Motor
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 2.61 kg
  • Dimensions: 26.6 mm x 131.2 mm x 169.8 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Kinetix Servo Motors
Quantità
Call sales Contact

Product Description

Description

The Allen-Bradley VPL-B1001M-CK12AA is a high-performance Low-Inertia Servo Motor built within the Kinetix 5500 motion system framework. This permanent magnet rotary motor provides optimal synchronization and peak operational density for automated machinery requiring rapid acceleration and deceleration profiles. Operating on a 400 V class AC power feed, the assembly utilizes a single magnet stack design coupled with a smooth mechanical shaft output interface to minimize mechanical friction. For real-time position observation and control network integration, the unit features an absolute single-turn digital feedback encoder utilizing the Hiperface DSL communication protocol to transmit high-resolution motor performance data through a single cable structure.

Features

  • Low-inertia permanent magnet architecture engineered explicitly for rapid acceleration and sudden deceleration dynamics.
  • Single right-angle SpeedTec DIN connector capable of up to 325 degrees of rotation to simplify cable routing inside compact control panels.
  • Integrated Hiperface DSL digital encoder protocol facilitating high-resolution, single-turn absolute feedback over a single connection interface.
  • Standard mechanical mounting pilot setup designed to assist machine builders with accurate structural positioning and shaft alignment.

Applications

  • High-speed industrial material handling and automated packaging networks.
  • Precision multi-axis machine tool positioning and manufacturing assembly tables.
  • Dynamic motion control applications within the Kinetix 5500 drive system platform.

Technical Specifications

Parameter Specification
Manufacturer Allen-Bradley / Rockwell Automation
Model Number VPL-B1001M-CK12AA
Product Line Kinetix VP Low-Inertia Servo Motors
Voltage Class 400 V AC
Frame Size 100 mm
Rated Speed 6000 RPM
Magnet Stacks 1
Feedback Type 18-bit absolute single-turn digital encoder
Communication Protocol Hiperface DSL
Shaft Design Smooth
Connector Configuration Single right-angle SpeedTec DIN, 325 degree rotatable
Mounting Flange Type IEC metric with free mounting holes (Type FF)
Factory Mechanical Options Standard, without brake
Net Weight 5.75 lbs (2.61 kg)
Motor Width (Front Side) 26.6 mm (1.05 Inches)
Motor Height 131.2 mm (5.17 Inches)
Motor Length (Side View) 169.8 mm (6.68 Inches)

Installation Guidelines

  • Environmental Limits: Ensure the ambient operating temperature surrounding the housing does not exceed 40 Celsius (104 Fahrenheit) to prevent accelerated thermal winding degradation.
  • Mounting Alignment: Use the built-in mounting pilot and the Type FF IEC metric free mounting holes to align the smooth shaft accurately with the driven machine load, reducing radial bearing wear.
  • Orientation and Ingress Control: Note that moisture protection performance depends on installation alignment. Mounting the assembly with the shaft down provides optimized positioning, while horizontal configurations guard against vertical dripping water; avoid positioning the shaft pointing upward as it provides no protection against fluid entry.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What feedback protocol does the motor use to communicate position data?
The motor features an 18-bit absolute single-turn digital encoder that transmits data using the Hiperface DSL protocol through a single integrated interface.
Does this specific servo motor configuration include an internal holding brake?
No, this configuration has standard factory options and comes without an integrated mechanical brake.
How does the mounting position affect the device protection from water?
The protection level varies by alignment: mounting with the shaft down is ideal, a horizontal shaft position protects against vertical water dripping, and a shaft-up position offers no fluid entry protection.
