BECKHOFF CP6629-0000-0020 CP66xx Built-in Panel PC

SKU CP6629-0000-0020

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: CP6629-0000-0020
Origin Germany
Product Type: Built-in Panel PCs
Payment: T/T, Western Union
Weight: 7.0 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Designed for space-saving control cabinet installation, the BECKHOFF CP6629-0000-0020 serves as a compact, high-performance built-in Panel PC engineered for mid-range PLC and motion control applications. This industrial HMI combines a robust 6.5-inch TFT display with an efficient ARM Cortex-A8 processor running at 1 GHz, making it highly optimized for TwinCAT 2 and TwinCAT 3 automation environments.

The unit features a single-finger touch screen integrated into a durable aluminum front bezel, paired with a sheet-steel rear cover for industrial-grade protection. With its onboard EtherCAT interface and dedicated Ethernet port, the CP6629-0000-0020 acts as a reliable controller or client terminal within decentralized control networks. It also incorporates non-volatile NOVRAM to ensure critical process data is retained during sudden power interruptions.

Features

High-Performance Processing: Powered by an ARM Cortex-A8 1 GHz processor, providing efficient execution of control logic and visualization tasks.
Industrial Display: 6.5-inch TFT display with 640 x 480 resolution and integrated single-finger touch technology.
Dual Network Interfaces: Features 1 x 10/100BASE-T Ethernet port and 1 x dedicated EtherCAT port for seamless fieldbus integration.
Data Security: Equipped with 128 kByte NOVRAM persistent memory and an integrated 1-second UPS to prevent data loss.
Rugged Construction: IP65-rated front panel protection against dust and moisture, with an IP20-rated rear enclosure.
Flexible Storage: Includes a microSD card slot supporting storage capacities from 512 MB up to 16 GB.

Applications

Machine Tool Automation: Compact operator interface for localized CNC and PLC control systems.
Packaging Machinery: High-speed control and monitoring of packaging lines via real-time EtherCAT communication.
Material Handling: Embedded controller for conveyor systems, sorting systems, and automated guided vehicles (AGVs).
Building Automation: Centralized visualization and control terminal for HVAC and lighting networks.

Technical Specifications

Parameter	Specification
Manufacturer	Beckhoff Automation GmbH & Co. KG
Part Number / Model	CP6629-0000-0020
Device Type	Built-in Panel PC
Display Size / Type	6.5-inch TFT
Resolution	640 x 480 pixels
Touch Screen	Single-finger touch screen
Processor	ARM Cortex-A8, 1 GHz (TwinCAT 2/3 performance class: 30)
Motherboard	3.5-inch motherboard
Memory	1 GB DDR3 RAM
Storage Slot	1 x microSD slot (supports 512 MB to 16 GB)
Persistent Memory	128 kByte NOVRAM
Graphic Adapter	Integrated in processor
Ethernet Interfaces	1 x 10/100BASE-T on-board
EtherCAT Interfaces	1 x on-board
Serial Interfaces	1 x RS232
USB Ports	2 x USB 2.0
Operating System	Windows Embedded Compact 7 (English)
Power Supply	24 V DC (with integrated 1-second UPS)
Protection Rating	Front side IP65, rear side IP20
Operating Temperature	0 to 55 degC
Housing Material	Aluminum front with sheet-steel rear cover
Shipping Weight	Approx. 7.0 kg

Connections and Interfaces

Connector / Port	Function
LAN (RJ45)	10/100BASE-T Ethernet connection for network integration
EtherCAT (RJ45)	Dedicated real-time EtherCAT fieldbus connection
USB 1 / USB 2	2 x USB 2.0 ports for external keyboard, mouse, or storage media
COM1 (D-sub)	RS232 serial interface for legacy device communication
Power Input	24 V DC power supply terminal connection
MicroSD Slot	External system storage and operating system boot media

Installation Guidelines

Mounting Method: Utilize the integrated pull-out clamping levers for fast, secure installation into control cabinet doors or console panels without loose parts.
Environmental Considerations: Ensure the ambient operating temperature remains between 0 and 55 degC. Maintain adequate clearance behind the rear cover for natural convection cooling.
Grounding and Shielding: Connect the functional earth terminal on the rear cover to the central ground bus of the control cabinet using a low-impedance conductor.
Cable Routing: Route communication cables (EtherCAT and Ethernet) separately from high-voltage AC power lines to minimize electromagnetic interference.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary processor used in the Beckhoff CP6629-0000-0020?

The CP6629-0000-0020 is powered by an ARM Cortex-A8 processor running at 1 GHz, optimized for TwinCAT 2 and TwinCAT 3 runtime environments.

What are the display specifications for this Panel PC?

It features a 6.5-inch TFT display with a resolution of 640 x 480 pixels and an integrated single-finger touch screen.

Does the CP6629-0000-0020 include non-volatile memory?

Yes, it includes 128 kByte of NOVRAM persistent memory to retain critical data during power loss, supported by an integrated 1-second UPS.

What is the ingress protection (IP) rating of this device?

The front panel of the Panel PC is rated IP65, providing protection against dust and water jets, while the rear housing is rated IP20.

What operating system comes pre-installed on the CP6629-0000-0020?

The device comes with Windows Embedded Compact 7 (English version) pre-installed.
