The EL9222-5500 is a 2-channel overcurrent protection terminal for 24 V DC applications, designed to provide precise electronic circuit protection within the Beckhoff EtherCAT terminal system. This terminal features an adjustable rated current from 1 A to 10 A in 1 A steps, with a maximum total sum current of 10 A. The module integrates advanced monitoring functions, including a 90% advance warning output load and an integrated 15 A fail-safe element per channel, ensuring operational reliability and equipment safety in industrial automation environments.
| Feature | Specification |
|---|---|
| Manufacturer | Beckhoff |
| Technology | Overcurrent protection terminal 24 V DC |
| Number of Channels | 2 |
| Nominal Voltage | 24 V DC |
| Rated Current | Adjustable 1…10 A (in 1 A steps) |
| Total Current (∑) | Max. 10 A |
| E-bus Consumption | Typ. 80 mA |
| Electrical Isolation | 500 V (E-bus/signal voltage) |
| Dimensions | 12 mm x 100 mm x 68 mm |
| Weight | Approx. 55 g |
| Operating Temperature | 0…+55 degC |
| Storage Temperature | -25…+85 degC |
| Protection Rating | IP20 |
| Approvals | CE, cULus, cURus |
