Bently Nevada

Bently Nevada 115M7750-01 3500/15 High Voltage DC Power Input Module

SKU 115M7750-01

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 115M7750-01
  • Origin United States
  • Product Type: DC Power Input Module
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.34 kg
  • Dimensions: 120.7 × 25.4 × 114.3 mm (H × W × D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3500/15 DC Power Input Module

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 115M7750-01 3500/15 High Voltage DC Power Input Module

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The 115M7750-01 High Voltage DC Power Input Module (PIM) is a rear-mount power interface component designed for the Bently Nevada 3500/15 AC and DC Power Supplies system. Installed directly behind the corresponding front-facing power supply module, the 115M7750-01 provides the primary high-voltage DC power connection and input conditioning for the 3500 Series Machinery Protection System rack.

It connects an external high-voltage DC source to the front-facing 114M5329-01 High Voltage DC Power Supply Module. This allows incoming voltage to be safely routed and converted for internal rack utilization.

Features

  • Accepts a high-voltage DC input range from 88 Vdc to 140 Vdc.
  • Uses a half-height rear module footprint directly behind the associated power supply.
  • Works with the 3500/15 High Voltage DC Power Supply Module, part number 114M5329-01.
  • Includes onboard fuse protection against over-voltage conditions.
  • Under-voltage conditions do not damage the module or power supply.
  • Supports hot-swappable replacement in dual-redundant power configurations without interrupting rack operation.

Applications

  • High-voltage DC-powered 3500 Series Machinery Protection System racks.
  • Turbomachinery vibration and condition monitoring systems.
  • Continuous machinery protection in oil and gas facilities.
  • Power generation plants.
  • Chemical and process industry installations.

Technical Specifications

Parameter Specification
Manufacturer Bently Nevada / Baker Hughes
Model / Part Number 115M7750-01
Module Type High Voltage DC Power Input Module (PIM)
System Compatibility 3500/15 Power Supply System
Input Voltage Range 88 to 140 Vdc
Full Rack Current Draw 2.5 A maximum
Over-Voltage Protection Over-voltage causes the fuse on the PIM to open
Under-Voltage Protection Under-voltage does not damage the power supply or PIM
Replacement Fuse Part Number 129M0198
Dimensions (H × W × D) 120.7 × 25.4 × 114.3 mm (4.75 × 1.0 × 4.5 in)
Weight 0.34 kg (0.75 lb)
Operating Temperature -30°C to +65°C (-22°F to +150°F)
Storage Temperature -40°C to +85°C (-40°F to +185°F)
Humidity 95%, non-condensing

Installation Guidelines

  • Rack Location: Install the module in the special half-height slot at the rear of the rack. It must be positioned directly behind the associated front-facing 3500/15 High Voltage DC Power Supply Module.
  • Redundancy Configuration: In a dual-supply system, the PIM can be inserted or replaced without interrupting rack operation, provided the second power supply remains operational.
  • Wiring and Terminal Safety: Verify that the DC power connection remains within the specified 88 to 140 Vdc range. Confirm the correct polarity before applying input power.
  • Protection and Fusing: An over-voltage event will cause the PIM fuse to open. Replace it only with the specified 129M0198 replacement fuse.

Compliance and Certifications

  • FCC: Part 15, Class A.
  • EMC Directives: European Community Directive 2014/30/EU; EN 61000-6-2; EN 61000-6-4.
  • Electrical Safety: European Community Directive 2014/35/EU; EN 61010-1.
  • RoHS: European Community Directive 2011/65/EU.
  • Maritime Approvals: DNV GL rules for classification; ABS Rules for Conditions of Classification.
  • Hazardous Area Approvals: Class I, Zone 2: AEx/Ex nA nC ic IIC T4 Gc; AEx/Ex ec nC ic IIC T4 Gc; Class I, Division 2, Groups A, B, C, and D. T4 at Ta = -20°C to +65°C.
  • ATEX / IECEx: II 3 G; Ex nA nC ic IIC T4 Gc; Ex ec nC ic IIC T4 Gc. T4 at Ta = -20°C to +65°C.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What happens if an over-voltage condition occurs on the module?
An over-voltage condition on the module causes the internal fuse on the power input module to open to protect the rack electronics.
Will an under-voltage condition damage the power input module?
No, an under-voltage condition does not harm the power supply or the power input module.
Is it possible to replace the power module without shutting down the system?
Yes, if two power supplies are installed in the rack, removing or inserting a power supply module does not disrupt rack operation.
