177314-02 | Bently Nevada | Air Driven TK-3g

Bently Nevada

Bently Nevada 177314-02 TK-3g Air Driven Calibration Instrument

SKU 177314-02

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 177314-02
  • Origin United States
  • Product Type: Calibration Instruments
  • Payment: T/T, Western Union
  • Weight: 5.22 kg
  • Dimensions: 19.5 cm x 29.9 cm x 24.8 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Calibration Instruments TK-3
Quantità
Call sales Contact

Product Description

Description

Designed for in-field verification and calibration of proximity probe systems, the Bently Nevada 177314-02 is a pneumatic, air-driven calibration instrument. This high-precision device simulates shaft vibration and position, enabling maintenance technicians to verify the calibration of Bently Nevada proximity probe systems, transducers, and machinery protection monitors.

As an air-driven model, this unit is highly suited for environments where electrical power is unavailable, restricted, or where hazardous area regulations make pneumatic tools preferable. The 177314-02 configuration features metric scale units (micrometer graduated in metric increments) to align with standard international industrial instrumentation. It is housed in a rugged enclosure that protects the delicate mechanical components from field hazards.

Features

  • Pneumatic, air-driven operation eliminating the need for electrical power sources during field testing.
  • Vibration and position calibration capability using a metric spindle assembly.
  • Wobble plate drive mechanism for simulating precise dynamic vibration amplitudes.
  • Rugged, IP54-rated enclosure (when closed) designed to protect sensitive calibration elements in harsh industrial environments.
  • Highly portable design suited for standard industrial field environments.

Applications

  • Field verification of proximity probe systems and dynamic transducers.
  • Calibration checks for machinery protection monitors and vibration transmitters.
  • Use in refineries, petrochemical plants, power generation stations, and gas processing facilities.

Technical Specifications

Manufacturer Bently Nevada
Part Number 177314-02
Series / Product Family TK-3g (TK-3G Air Driven)
Scale Units Metric (02 option)
Power Requirements 90 psi (6.2 bar) maximum (pneumatic feed)
Maximum Speed 0 to 5000 cpm ± 1000 cpm
Enclosure Rating Designed to meet IP54 for dust and water exposure (when closed)
Humidity Limits 95% non-condensing relative humidity
Storage Temperature Range -18 degC to 65 degC (0 degF to 150 degF)
Operational Temperature Range 0 degC to 54 degC (32 degF to 130 degF)
Dimensions (H x W x D) 19.5 cm x 29.9 cm x 24.8 cm
Weight 5.22 kg
Country of Origin United States

Installation Guidelines

  • Ensure the supplied pneumatic air source is dry, clean, and does not exceed the maximum rating of 90 psi (6.2 bar).
  • Place the instrument on a flat, stable, and vibration-free surface during calibration procedures to prevent external interference.
  • Keep the protective transport cover closed when moving the instrument through wet or dusty field environments to preserve the IP54 protection level.

Compliance and Certifications

  • IP54 rating (when closed) for environmental protection against dust and water ingress.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the Bently Nevada 177314-02?
The Bently Nevada 177314-02 is a pneumatic, air-driven TK-3g calibration instrument used to verify the calibration of Bently Nevada proximity probe systems and machinery protection monitors in the field.
What scale units does the 177314-02 model feature?
This model is equipped with metric scale units (micrometer graduated in metric increments).
Does this calibration instrument require electrical power?
No, the 177314-02 is completely air-driven and requires a pneumatic input source (maximum 90 psi or 6.2 bar) instead of electrical power.
What is the maximum speed capacity of the TK-3g Air Driven calibrator?
The maximum speed ranges from 0 to 5000 cpm ± 1000 cpm.
