The 190501-00-00-CN is a Velomitor CT Velocity Transducer, configured with the Option 00 mounting and connection interface and the -CN suffix for China hazardous area compliance. This piezoelectric velocity sensor is a specialized low-frequency version of the standard Velomitor transducer, designed to measure casing vibration velocity on rotating machinery such as cooling tower fans and air-cooled heat-exchanger fan assemblies. It operates effectively on machinery with rotation speeds typically at or above 90 rpm (100 to 300 rpm typical).
This transducer converts machine casing motion into a proportional voltage output, providing a critical signal for vibration monitoring systems. The 190501-00-00-CN variant features a 3/8-24 mounting interface (No Stud - Option 00) and a standard MIL-C-5015 connection interface (Option 00). The -CN suffix indicates the inclusion of hazardous area approval documentation for China (NEPSI and CCC), ensuring compliance with regional safety standards.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 190501-00-00-CN | Velomitor CT Velocity Transducer |
| A - Mounting Hardware | 00 | No stud |
| B - Connection Option | 00 | MIL-C-5015 connection interface |
| Suffix | -CN | China hazardous area approval package (NEPSI + CCC) |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model | 190501-00-00-CN |
| Sensitivity | 3.94 mV/mm/s (100 mV/in/s) +/- 5% |
| Frequency Response | 3.0 Hz to 900 Hz +/- 1.0 dB; 1.5 Hz to 1.0 kHz +/- 3.0 dB |
| Operating Temperature | -40 degC to +85 degC (-40 degF to +185 degF) |
| Case Material | 316L stainless steel |
| Weight | < 297 g (10.5 oz) typical |
| Connector | 2-pin 316L stainless steel MIL-C-5015, top |
| Grounding | Internal electronics isolated from case |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 190501-00-00-CN
Country of origin:United States
Product Type: Velomitor CT Velocity Transducer
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 297g
Dimensions: 1.8cm x 1.6cm x 123cm
Shipping port: Xiamen
Warranty: 12 months
