190501-10-00-00 Velomitor CT Velocity Transducer is specified with Option 10 mounting hardware (Plate Stud M6x1 to M6x1 with a 3/8-in 24 adapter), Option 00 standard top-mounted MIL-C-5015 connection interface, and Option 00 general-purpose configuration with no agency approvals. This low-frequency piezo-velocity sensor measures casing vibration velocity on cooling tower and air-cooled heat-exchanger fan assemblies operating at or above 90 rpm (typically 100 to 300 rpm). By capturing vibration amplitudes and frequencies generated by the fan motor and speed reducer, it supports early detection of mechanical issues such as unbalance and misalignment.
Unlike configurations carrying hazardous area certifications (Options 01 through 04) or using other stud sizes, the 190501-10-00-00 is suited for general-purpose, non-certified industrial environments. The M6x1 to M6x1 plate stud with a 3/8-in 24 adapter mounts on metric-threaded machine casings. Internal sensor electronics are electrically isolated from the 316L stainless steel case to prevent ground loop noise, maintaining signal integrity.
| Option / Segment | Code on This SKU | Description / Meaning |
|---|---|---|
| Orderable Part Number | 190501-10-00-00 | Velomitor CT Velocity Transducer, general purpose configuration |
| A - Mounting Hardware Option | 10 | Plate Stud M6x1 to M6x1 with 3/8-in 24 adapter |
| B - Connection Option | 00 | MIL-C-5015 connection interface |
| C - Agency Approval Option | 00 | No Approvals (General Purpose) |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / SKU | 190501-10-00-00 |
| Transducer Type | Low-frequency piezo-velocity sensor |
| Sensitivity | 3.94 mV/mm/s (100 mV/in/s) +/-5% at 100 Hz |
| Frequency Response (+/-1.0 dB) | 3.0 Hz to 900 Hz (180 to 54,000 cpm) |
| Frequency Response (+/-3.0 dB) | 1.5 Hz to 1.0 kHz (90 to 60,000 cpm) |
| Output Bias Voltage | 10.1 Vdc +/-1.0 Vdc (Pin A referenced to Pin B) |
| Velocity Range | 63.5 mm/s pk (2.5 in/s pk) |
| Dynamic Output Impedance | Less than 400 ohms typical |
| Resonant Frequency | 9 kHz minimum (stud mounted) |
| Grounding | Internal electronics isolated from case |
| Operating Temperature | -40 degC to +85 degC (-40 degF to +185 degF) |
| Storage Temperature | -40 degC to +100 degC (-40 degF to +212 degF) |
| Shock Limit | 5000 g pk maximum |
| Humidity Limit | 100% condensing, non-submerged |
| Case Material | 316L stainless steel |
| Connector Type | 2-pin 316L stainless steel MIL-C-5015 (top-mounted) |
| Weight | Less than 297 g (10.5 oz) typical |
| Mounting Torque | 4.5 N-m +/-0.6 N-m (40 in-lbf +/-5 in-lbf) |
| Mounting Surface | 33 mm (1.3 in) diameter |
| Height | 82 mm (3.2 in) |
The standard MIL-C-5015 connection interface provides electrical output signal connections as defined below:
| Pin | Function |
|---|---|
| Pin A | Positive output signal (goes positive with respect to Pin B when velocity is from base to top of the transducer) |
| Pin B | Negative/Return output signal |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 190501-10-00-00
Country of origin:United States
Product Type: Velomitor CT Velocity Transducer
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 297g
Dimensions: 33 mm x 33 mm x 82 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
