The 21000-28-05-00-092-03-02 is a Bently Nevada proximity probe housing assembly designed for industrial machinery vibration monitoring applications. This configuration features a 3300 XL 8 mm proximity probe (Option 28) with selectable hazardous area approvals and a 0.5 m (20 in) integral probe cable (Option 05). The housing is configured without a standoff adapter (Option 00) and includes a probe penetration length defined by the 092 option code. It is equipped with a cable seal grip fitting (Option 03) and 3/4-14 NPT mounting threads (Option 02).
This housing assembly provides robust mechanical protection for the probe and cable in demanding environments, ensuring consistent signal integrity for axial position and vibration measurements. It is engineered for compatibility with 3300 XL transducer systems, facilitating reliable shaft monitoring in diverse rotating machinery such as turbines, compressors, and pumps.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 21000-28-05-00-092-03-02 | 21000 Proximity Probe Housing Assembly |
| AA - Probe | 28 | 3300 XL 8 mm probe, selectable hazardous area approvals |
| BB - Probe Cable Length | 05 | 0.5 m (20 in) |
| CC - Standoff Adapter | 00 | No standoff adapter |
| DDD - Probe Penetration | 092 | Specified penetration depth |
| EE - Fittings | 03 | One cable seal grip with grommets |
| FF - Mounting Thread | 02 | 3/4-14 NPT |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 21000-28-05-00-092-03-02 |
| Body Material | Aluminum body with 304 stainless steel sleeve |
| Operating Temperature | -51 degC to +177 degC (-60 degF to +351 degF) |
| Weight | 1.1 kg (2.4 lb) typical |
| Probe Compatibility | 3300 XL 8 mm |
| Mounting Thread | 3/4-14 NPT |
Ensure the probe is installed with the correct gap as specified by the transducer system documentation. When using the cable seal grip (Option 03), select the appropriate grommet size to ensure a proper moisture and dust seal. If the total probe penetration length exceeds 300 mm (12 in), additional sleeve support is required to prevent vibration-induced resonance. Always verify machine case conditions for counter-boring requirements if probe penetration is less than 1.0 inch.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 21000-28-05-00-092-03-02
Country of origin:United States
Product Type: Proximity Probe Housing Assemblies
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 1100g
Dimensions: 8.5cm x 8.5cm x 30.5cm
Shipping port: Xiamen
Warranty: 12 months
