The 21504-000-008-10-02 is a 7200 Series 5 mm and 8 mm standard mount proximity probe used in eddy-current displacement transducer systems. This specific configuration features a 0.0 in (0 mm) unthreaded length (Option 000), an 8.0 in (203 mm) case length (Option 008), a 1.0 m (3.3 ft) total length (Option 10), and a miniature coaxial connector (Option 02). This probe is designed for critical machinery monitoring applications, providing accurate shaft vibration and position data when paired with compatible 7200 series Proximitor sensors and extension cables.
The 7200 Series transducers are specifically engineered to provide linear voltage output proportional to the distance between the probe tip and the observed conductive surface. The selection of the 008 case length and 000 unthreaded length ensures proper mounting in industrial machinery housings where specific probe-to-target gaps are maintained for reliable signal transduction.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 21504-000-008-10-02 | 7200 Series 5 mm and 8 mm Standard Mount Probe |
| A - Unthreaded Length | 000 | 0.0 in (0 mm) |
| B - Case Length | 008 | 8.0 in (203 mm) |
| C - Total Length | 10 | 1.0 m (3.3 ft) |
| D - Connector | 02 | Miniature coaxial connector |
| Manufacturer | Bently Nevada | |
| Part Number | 21504-000-008-10-02 | |
| Probe Diameter | 5 mm / 8 mm (System specific) | |
| Case Length | 8.0 in (203 mm) | |
| Unthreaded Length | 0.0 in (0 mm) | |
| Total Length | 1.0 m | |
| Connector Type | Miniature coaxial | |
| Linear Range | Typically 80 mils (2 mm) | |
| System Compatibility | 7200 Series Proximitor Sensors |
Ensure the probe is installed in a rigid mount to minimize mechanical resonance. Use appropriate locknuts to secure the probe position relative to the target surface. Maintain the specified air gap as defined in the 7200 series monitoring system documentation to ensure linear output voltage. Cables should be routed in conduit or protected raceways to prevent electromagnetic interference and physical damage. Ensure all connections are clean and fully seated to prevent signal noise.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 21504-000-008-10-02
Country of origin:United States
Product Type: 5 mm and 8 mm Standard Mount Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 20g
Dimensions: 10cm x 10cm x 1.5cm
Shipping port: Xiamen
Warranty: 12 months
