The 31000-16-05-20-040-02-02 is a configuration of the 31000 series proximity probe housing assemblies, specifically tailored for 3300 XL 8 mm transducer systems. This assembly features a 0.5 m (20 in) probe cable (Option 05), a 200 mm standoff adapter (Option 20), and a 40 mm probe penetration (Option 040). It is equipped with two M25 fittings and one plug (Option 02) and utilizes a 3/4-14 NPT mounting thread (Option 02), which is required to accommodate the included standoff adapter.
This housing assembly provides a protective environment for the transducer cabling and connections, isolating them from the machine case and external industrial conditions. It is engineered for use in machinery protection applications where precise shaft vibration and axial position measurements are required. The assembly includes flexible component options to accommodate various mounting thread requirements and cable entry points, ensuring compatibility with standard plant conduit configurations.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 31000-16-05-20-040-02-02 | 31000 Proximity Probe Housing Assembly |
| A - Probe with Connector | 16 | 3300 XL 8 mm probe |
| B - Probe Cable Length | 05 | 0.5 m (20 in) |
| C - Standoff Adapter Length | 20 | 200 mm |
| D - Probe Penetration | 040 | 40 mm |
| E - Fittings | 02 | Two M25 fittings, one plug |
| F - Mounting Thread | 02 | 3/4-14 NPT |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model | 31000-16-05-20-040-02-02 |
| Probe Compatibility | 3300 XL 8 mm |
| Standoff Adapter | 200 mm |
| Probe Penetration | 40 mm |
| Mounting Thread | 3/4-14 NPT |
| Fittings | Two M25 fittings, one plug |
| Housing Material | Stainless steel / Aluminum (per datasheet standard) |
Ensure the outer sleeve is correctly installed into the machine case before fitting the housing. Adjust the probe gap according to standard 3300 XL system documentation after inserting the probe sleeve. When using the standoff adapter, confirm that the 3/4-14 NPT thread is fully engaged. If using hole plugs, tighten the plug nuts to 0.5 N-m (5 in-lbs) to maintain the integrity of the housing environment. Ensure all conduit fittings are properly secured if using hardline or rigid conduit.
