The 330101-00-08-10-02-00 is a 3300 XL 8 mm proximity probe configuration featuring a 3/8-24 UNF thread and a non-armored design. This unit is specified with a 0.0 in unthreaded length (Option 00), a 0.8 in case length (Option 08), and a 1.0 meter total system length (Option 10). It utilizes a miniature coaxial ClickLoc connector on a standard cable (Option 02) and does not require hazardous area approvals (Option 00).
As a core component of the 3300 XL 8 mm proximity transducer system, this probe provides accurate, non-contact eddy-current displacement measurement for monitoring shaft vibration and axial position. It is engineered to operate seamlessly with 3300 XL Proximitor sensors and 3300 XL extension cables to ensure signal integrity across the entire monitoring chain.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330101-00-08-10-02-00 | 3300 XL 8 mm Proximity Probe |
| A - Unthreaded Length | 00 | 0.0 in unthreaded length |
| B - Case Length | 08 | 0.8 in case length |
| C - Total Length | 10 | 1.0 meter total length |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Model | 330101 |
| Probe Diameter | 8 mm |
| Thread Size | 3/8-24 UNF |
| Total System Length | 1.0 meter |
| Connector Type | Miniature coaxial ClickLoc |
| Cable Type | Standard |
| Case Length | 0.8 in |
| Unthreaded Length | 0.0 in |
| Operating Temperature | -52 degC to +177 degC |
| Material | A308 Aluminum (Proximitor), Gold-plated brass (Connector) |
Ensure correct probe gapping during installation to maintain linear output range. Use standard Bently Nevada mounting brackets and verify that the connector-to-connector interface is finger-tightened to prevent signal degradation. For long-term reliability in harsh environments, consider using connector protectors to prevent moisture and contaminant ingress.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330101-00-08-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
