Option 00 (0.0 in unthreaded), Option 20 (2.0 in case), Option 10 (1.0 m total length), and Option 02 (Miniature ClickLoc, standard cable) specify this 330101-00-20-10-02-05 configuration of the 3300 XL 8 mm Proximity Probe. This non-contact, eddy-current transducer is a foundational component of the 3300 XL 8 mm monitoring system, designed for precise displacement measurement in industrial rotating machinery.
The 330101 probe features a 3/8-24 UNF thread and is an unarmored configuration. It is engineered to pair specifically with the 3300 XL Proximitor sensor and extension cable, maintaining system performance across a broad temperature range. This unit provides the necessary reliability for continuous monitoring of shaft vibration and axial position in turbines, compressors, pumps, and fans.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330101-00-20-10-02-05 | 3300 XL 8 mm Proximity Probe, 3/8-24 UNF |
| A - Unthreaded Length | 00 | 0.0 in (fully threaded) |
| B - Case Length | 20 | 2.0 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 02 | Miniature ClickLoc, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330101-00-20-10-02-05 |
| Probe Diameter | 8 mm |
| Thread Size | 3/8-24 UNF-2A |
| Case Material | AISI 303/304 Stainless Steel |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Cable Type | 75 Ohm triaxial, FEP insulated (standard) |
| Connector | Miniature ClickLoc coaxial |
| Operating Temperature | -51 degC to +177 degC |
| Max Connector Torque | 0.565 Nm |
| Max Case Torque | 11.2 Nm |
Ensure the probe is gapped according to system calibration requirements (typically 1.27 mm). Use the recommended 3300 XL mounting brackets to secure the probe, ensuring that mounting screws are tightened to appropriate torque specifications. For hazardous area installations, adhere to local regulations regarding intrinsic safety barriers and cable routing. Keep connectors clean and free of moisture or oil contamination during installation; use the included silicone tape or appropriate protectors if the connection is exposed to industrial environments.
